Three Phase Inverter /2 MPPTS Shangneng Electric SN12(X)/15/17/20/25PT

Name: Three Phase Inverter /2 MPPTS Shangneng Electric SN12(X)/15/17/20/25PT
SKU: 22296
Availability: InStock

Dimensions(WH*D)/mm：580*430*270

Max operating altitude/m：4000(>3000 derating)

Cooling method：Natural

Humidity：0-100%

Operating temperature/ C：-25-60

Protection level：IP66

Topology：Transformerless

Self-consuming at night：<1W

Price range: $755.00 through $1,024.00

power

Clear

Inverter characteristics:

Parameter：
