SUNGROW Solar Inverter
Showing all 16 results
-
SUNGROW Solar Inverter
SG8.0RS-L Sungrow Solar Inverter 12kW Single-MPPT String Inverter for 600 Vdc System Inverter with LED Digital Display & LED Indicator
SUNGROW Solar InverterSG8.0RS-L Sungrow Solar Inverter 12kW Single-MPPT String Inverter for 600 Vdc System Inverter with LED Digital Display & LED Indicator
Dimensions ( W * H * D ) : 525 mm * 365 mm * 170 mm
Weight : 18 kg
Mounting method : Wall-mounting bracket
Topology : Transformerless
Degree of protection : IP65
Operating ambient temperature range : -25 ℃ – 60 ℃
Allowable relative humidity range ( non-condensing ) : 0 – 100 %
Cooling method : Natural cooling
Max. operating altitude : 4000 mSKU: n/a -
SUNGROW Solar Inverter
Solar Inverter SUNGROW SG15/17/20RT Three Phase SUNGROW On Grid Solar Inverter Multi-MPPT String Inverter for 1000 Vdc System
SUNGROW Solar InverterSolar Inverter SUNGROW SG15/17/20RT Three Phase SUNGROW On Grid Solar Inverter Multi-MPPT String Inverter for 1000 Vdc System
- Dimensions (W*H*D): 370mm*480mm*195mm
- Weight: 21kg
- Mounting method: Wall-mounting bracket
- Topology: Transformerless
- Degree of protection: IP65
- Night power consumption: ＜6W
- Corrosion: C5
- Operating ambient temperature range: -25ºC to 60ºC
- Allowable relative humidity range (non-condensing) : 0%-100%
- Cooling method: Smart forced air cooling
- Max. operating altitude: 4000m
- Display: LED
- Communication: WLAN/Ethernet/RS485/DI/DO
- DC connection type: MC4(Max.6mm²)
- AC connection type: Plug and play
SKU: n/a -
SUNGROW Solar Inverter
Sungrow High Performance Inverter SG8.0/9.0/10RS Multi-MPPT String Inverter for 600 Vdc System Residential Triple Phase AC Inverters
SUNGROW Solar InverterSungrow High Performance Inverter SG8.0/9.0/10RS Multi-MPPT String Inverter for 600 Vdc System Residential Triple Phase AC Inverters
Dimensions (W*H*D) : 490 * 340 * 170 mm
Weight : 19 kg
Mounting method : Wall-mounting bracket
Topology : Transformerless
Degree of protection : IP65
Operating ambient temperature range : -25 to 60 ℃
Allowable relative humidity range (non-condensing) : 0 – 100 %
SKU: n/a -
SUNGROW Solar Inverter
Sungrow Inverter SG285HX for Spain and Germany Multi-MPPT String Inverter for 1500 Vdc System 285kW Hybrid Solar Inverter
SUNGROW Solar InverterSungrow Inverter SG285HX for Spain and Germany Multi-MPPT String Inverter for 1500 Vdc System 285kW Hybrid Solar Inverter
Dimensions (W*H*D) : 1136 * 870 * 361 mm
Weight : ≤ 116 kg
Isolation method : Transformerless
Degree of protection : IP66
Power consumption at night : < 6 W
Operating ambient temperature range : -30 to 60 ℃
Allowable relative humidity range : 0 – 100 %
Max. operating altitude : 4000 m (> 3000 m derating)
DC connection type : MC4-Evo2 (Max. 6 mm², optional 10mm² )
AC connection type : Support OT / DT terminal (Max. 400 mm²)SKU: n/a -
SUNGROW Solar Inverter
Sungrow Inverter SG3.0/3.6/4.0/5.0/6.0RS Double-MPPT String Inverter for 600 Vdc System Sungrow Hybrid Inverter Smart PID Recovery
SUNGROW Solar InverterSungrow Inverter SG3.0/3.6/4.0/5.0/6.0RS Double-MPPT String Inverter for 600 Vdc System Sungrow Hybrid Inverter Smart PID Recovery
Compatible with high power PV modules and bifacial modules
Integrated arc fault circuit interrupter
Built-in Type II DC&AC SPD
Corrosion protection rating at C5
One-click access to iSolarCloud monitoring platform
Real time data (10 seconds refresh sample)
24/7 live monitoring both online and with integrated display
Online IV curve scan and diagnosisSKU: n/a -
SUNGROW Solar Inverter
SUNGROW Inverter SG33/40/50CX 3 Phase 50Hz/60Hz LED Display 33KW 40KW 50KW Multi-MPPT String Solar Inverter for 1000 Vdc System
SUNGROW Solar InverterSUNGROW Inverter SG33/40/50CX 3 Phase 50Hz/60Hz LED Display 33KW 40KW 50KW Multi-MPPT String Solar Inverter for 1000 Vdc System
- Topology: Transformerless
- Degree of protection: IP66
- Night power consumption: ≤2W
- Operating ambient temperature range: -30 to 60ºC (> 45ºC derating)
- Allowable relative humidity range: 0–100 %
- Cooling method: Smart forced air cooling
- Max.operating altitude: 4000 m (> 3000 m derating)
- Display: LED, Bluetooth+APP
SKU: n/a -
SUNGROW Solar Inverter
Sungrow Inverter SG36CX-US North American Solar Inverter Suitable for 50Hz / 60Hz grid Three-Phase Hand Installation Inverters
SUNGROW Solar InverterSungrow Inverter SG36CX-US North American Solar Inverter Suitable for 50Hz / 60Hz grid Three-Phase Hand Installation Inverters
Dimensions ( W * H * D ) : Inverter: 702 mm * 595 mm * 310 mm ( 27.6” * 23.4” * 12.2” )
Wire-Box: 231 mm * 295 mm *234mm ( 9.1” * 11.6” * 9.2” )
Weight : 54 kg ( 119.0 lbs )
Ingress protection rating : Type 4X ( NEMA 4X, IP66 )
Operating ambient temperature range : -30 to 60 °C ( > 45 °C derating ) -22 to 140 °F ( > 113°F derating )
Allowable relative humidity range : 0 % – 100 %
Max. operating altitude : 4000 m / 13123.4 ft ( > 3000 m / 9842.5 ft derating )
Communication : RS485 / optional: WiFi and Ethernet
DC connection type : MC4 ( #12 – #10AWG )
AC connection type: OT ( #6 – 2/0AWG, Cu or Al )SKU: n/a -
SUNGROW Solar Inverter
Sungrow Inverter SG60CX-US North American Solar Inverter Suitable for 50Hz / 60Hz grid Three-Phase Hand Installation Inverters
SUNGROW Solar InverterSungrow Inverter SG60CX-US North American Solar Inverter Suitable for 50Hz / 60Hz grid Three-Phase Hand Installation Inverters
Dimensions ( W * H * D ) : Inverter: 782 mm * 645 mm * 310 mm ( 30.7” * 25.4” * 12.2” )
Wire-Box: 231 mm * 295 mm * 234 mm ( 9.1” * 11.6” * 9.2” )
Weight : 65 kg ( 143.3 lbs )
Ingress protection rating : Type 4X ( NEMA 4X, IP66 )
Operating ambient temperature range : -30 to 60 °C ( > 45 °C derating ) -22 to 140 °F ( > 113°F derating )
Allowable relative humidity range : 0 % – 100 %
Max. operating altitude : 4000 m / 13123.4 ft ( > 3000 m / 9842.5 ft derating )
Communication : RS485 / optional: WiFi and Ethernet
DC connection type : MC4 ( #12 – #10AWG )
AC connection type: OT ( #5 – 2/0AWG, Cu or Al )SKU: n/a -
SUNGROW Solar Inverter
Sungrow Inverter Solar Energy System SG25/30/33CX-P2 25kW 30kW 33kW On Grid Solar Inverter in Stock Multi-MPPT String Inverter
SUNGROW Solar InverterSungrow Inverter Solar Energy System SG25/30/33CX-P2 25kW 30kW 33kW On Grid Solar Inverter in Stock Multi-MPPT String Inverter
- Dimensions ( W * H * D ) : 645 mm * 575 mm * 245 mm
- Mounting Method : Wall-mounting bracket
- Weight : 38 kg
- Degree of protection : IP66
- Corrosion : C5
- Night power consumption : ＜5W
- Operating ambient temperature range : -30ºC – 60ºC
- Allowable relative humidity range (non-condensing) : 0% – 100 %
- Cooling method : Smart forced air cooling
- Max. operating altitude : 4000m
- Display: LED, Bluetooth+APP
SKU: n/a -
SUNGROW Solar Inverter
SUNGROW Multi-MPPT Solar Inverter SG110CX String Inverter for 1000 Vdc System 110KW On Grid Three Phase Solar Inverter
SUNGROW Solar InverterSUNGROW Multi-MPPT Solar Inverter SG110CX String Inverter for 1000 Vdc System 110KW On Grid Three Phase Solar Inverter
Low cost
(1) Compatible with Al and Cu AC cables (2) DC 2 in 1 connection enabled (3) Q at night function
Proven safety
(1) IP66 and C5 protection (2) Type II SPD for both DC and AC (3) Compliant with global safety and grid code
High yield
(1) 9 MPPTs with max. efficiency 98.7% (2) Compatible with bifacial modules (3)Built-in PID recovery function
Smart O&M
(1) Touch free commissioning and remote firmware upgrade (2) Online IV curve scan and diagnosis* (3) Fuse free design with smart string current monitoring
SKU: n/a -
SUNGROW Solar Inverter
SUNGROW Premium Inverter SG30CX 30KW Solar Inverter Price for Home Solar Power System Sungrow Three-phase Inverter Solar
SUNGROW Solar InverterSUNGROW Premium Inverter SG30CX 30KW Solar Inverter Price for Home Solar Power System Sungrow Three-phase Inverter Solar
- Dimensions (W*H*D): 702 * 595 * 310 mm
- Weight: 50 kg
- Topology: Transformerless
- Degree of protection: IP66
- Night power consumption: ≤2 W
- Operating ambient temperature range: -30 to 60ºC (> 45ºC derating)
- Allowable relative humidity range: 0 – 100 %
- Cooling method: Smart forced air cooling
SKU: n/a -
SUNGROW Solar Inverter
Sungrow SG333HX Inverter Multi-MPPT String Inverter for 1500 Vdc System High Efficiency Solar Inverter On-Grid Solar System 333KW
SUNGROW Solar InverterSungrow SG333HX Inverter Multi-MPPT String Inverter for 1500 Vdc System High Efficiency Solar Inverter On-Grid Solar System 333KW
- 2 strings per MPPT, no fear of string reverse connection
- 24h real-time AC and DC insulation monitoring
- Q at night function, save investment
- Power line communication (PLC)
- Smart IV Curve diagnosis*, active O&M
- Up to 16 MPPTs with max. efficiency 99%
- 20A per string, compatible with 500Wp+ module
- Data exchange with tracker system, improving yield
SKU: n/a -
SUNGROW Solar Inverter
SUNGROW SG350HX Inverter Multi-MPPT String Inverter for 1500 Vdc System 350kW On-Grid Solar System Sungrow Solar Inverter
SUNGROW Solar InverterSUNGROW SG350HX Inverter Multi-MPPT String Inverter for 1500 Vdc System 350kW On-Grid Solar System Sungrow Solar Inverter
Dimensions (W*H*D) : 1136 * 870 * 361 mm
Weight : ≤ 116 kg
Degree of protection : IP66
Power consumption at night : < 6 W
Operating ambient temperature range : -30 to 60℃
Allowable relative humidity range : 0 – 100 %
Display : LED, Bluetooth+APP
Communication : RS485 / PLC
DC connection type : MC4-Evo2 (Max. 6 mm², optional 10mm²)
AC connection type: Support OT/DT terminal (Max. 400 mm²)SKU: n/a -
SUNGROW Solar Inverter
Sungrow Solar Inverter SG5.0/6.0/7.0/8.0/10/12RT Multi-MPPT String Inverter for 1000 Vdc System Three Phase On Grid Solar Inverter
SUNGROW Solar InverterSungrow Solar Inverter SG5.0/6.0/7.0/8.0/10/12RT Multi-MPPT String Inverter for 1000 Vdc System Three Phase On Grid Solar Inverter
High yield
- Lower startup & wider MPPT voltage
- Compatible with bifacial modules
- Built-in PID recovery function
Smart management
- Smart IV curve scanning
- 24 / 7 Live monitoring
- Remote firmware updates
SKU: n/a -
SUNGROW Solar Inverter
Sungrow String Inverter SG125CX-P2 with Smart IV Curve Diagnosis 125kW On Grid Inverter Solar Energy Controller Easy for Remote O&M
SUNGROW Solar InverterSungrow String Inverter SG125CX-P2 with Smart IV Curve Diagnosis 125kW On Grid Inverter Solar Energy Controller Easy for Remote O&M
12 MPPTs with max. efficiency 98.5%
DC 15A current input, compatiable with over 500W+ PV module
Dynamic shading optimization mode
Compatible max. 240mm² Al AC cables
Drawer-style cable sealing plate support AC cable pre-assembly
Key component diagnosis and protection
Smart IV Curve Diagnosis
Grid fault record function, easy for remote O&MSKU: n/a -
SUNGROW Solar Inverter
SUNGROW String Inverter SG3.0RS-L Single-MPPT String Inverter for 600 Vdc System 3kW Solar Inverter Solar Energy System
SUNGROW Solar InverterSUNGROW String Inverter SG3.0RS-L Single-MPPT String Inverter for 600 Vdc System 3kW Solar Inverter Solar Energy System
Dimensions ( W * H * D ) : 360 mm * 263 mm * 125.5 mm
Weight : 6 kg
Degree of protection : IP65
Operating ambient temperature range : -25 ℃ – 60 ℃
Allowable relative humidity range ( non-condensing ) : 0 – 100 %
Max. operating altitude : 4000 m
Display : LED digital display & LED indicator
Communication : WLANSKU: n/a
