Beverage Equipment

• 20% top space to avoid beer foam out;
• Accommodate to brew 1/2 batches
• 2” pressure vacuum relief valve
• 1.5” sample valve
• Pressure gauge
• CIP – rotary spray ball
• CO2 blow off tube
• Multiple glycol zones
• Fully welded cladding
• Adjustable tank leveling pads
• Carb Stone 2” TC assembly
• RTD Probe
• 2″ Butterfly valves
• Tension braces on legs
• Good quality, reasonable price and excellent quality

Bright beer tank, also known as storage tank. The beer after the fermentation can be stored in the tank and have a further mature, and the filtered beer also can be stored in the tank to wait package. According to the different use of bright beer tank can be divided into single-layer BBT, double-layer sake BBT.

Our Brite Tank has 10% Head Space. All tank have a Dish top & bottom, Cylinder body. Certified stainless steel material for all tanks, with 100% TIG welded joints and seams with sanitary interior polish. Dimple Plate jacket for Glycol cooling & high efficient Polyurethane foam insulated. All tanks use Tri-clamp connections, are designed for up to 14.7 PSI and tested at 30 PSI.

• 15 PSI (1 bar) working pressure
• Side manway door for cleaning
• 1.5″ Tri-clamp carbonation stone
• 1.5″ Tri-clamp pressure gauge
• 1.5″ Tri-clamp dial face bi-metal, easy-read analog thermometer
• 1.5″ Tri-clamp Perlick-style sample valve
• 2″ Tri-clamp pressure/vacuum relief
• 2″ Center bottom tri-clamp drain
• Sight-glass for reading volumes
• Dedicated pipe system with 4″ Tri-clamp center top opening and 1.5″ tri-clamp rotating CIP spray ball for easy cleaning
• 3/4″ NPT glycol ports
• PT100 Thermocouple interface
• Shadowless Manway

Bright beer tanks,also called brite tank, is a piece of brewing equipment as they serve to mature, clarify, and carbonate the beer after fermentation. They are key components in the production of beer which are the final stop in the brewing process after leaving the brewhouse and fermenters.

They can also be used for both the storage of finished beer for later canning, bottling, and kegging and as serving vessels allowing unpackaged beer to be poured and served directly from the bright beer tank.

Cylindrical tanks for the final processing of refined beverages (serving tanks, filling tanks, serving tanks, storage tanks, BBT – Bright beer tank). This type of beverage production tanks has a horizontally stackable structure with thermal insulation layers and a double jacket cooled with ice water or ethylene glycol. It is a tank with a working capacity of 5000 liters. This purpose-built equipment is designed for the storage, serving, carbonation, filtration and preparation of beer, cider, wine and other beverages under pressure prior to filling into kegs and bottles. The container is available in several sizes and is made of food grade stainless steel. Containers include standardized dimensions and equipment, or are manufactured to individual customer requirements.
