Thermoforming Vacuum Packaging Machine for Meat Processing

Product introduction of Thermoforming Vacuum Packaging Machine

The Thermoforming Vacuum Packaging Machine is an automatic packaging system designed for meat processing plants, food factories, and ready meal producers. It integrates film forming, vacuum sealing, MAP gas flushing, heat sealing, and cutting into one efficient process. Built with food-grade stainless steel and intelligent control, it delivers stable packaging performance for fresh meat, poultry, seafood, pasta, and prepared foods while improving shelf life, hygiene, and production efficiency.

Working principle

The Thermoforming Vacuum Packaging Machine operates through a continuous rollstock packaging process.

Step 1: Film Feeding

The bottom packaging film is automatically transported into the forming station.

Step 2: Tray Forming

The heated film is softened and shaped into customized product cavities.

Step 3: Product Loading

Food products such as meat cuts, poultry, pasta, seafood, or ready meals are placed into formed cavities.

Step 4: Vacuum or MAP Processing

The sealing chamber removes air from the package or fills it with protective gas depending on product requirements.

Step 5: Heat Sealing

The upper film is sealed tightly with the bottom tray to create a secure package.

Step 6: Package Cutting

The machine automatically separates individual finished packages.

Step 7: Product Transfer

Finished products move to downstream processes such as labeling, inspection, and distribution.

Product Parameter Table

Parameter	Specification
Machine Type	Thermoforming Vacuum Packaging Machine
Application	Meat, Poultry, Seafood, Pasta, Ready Meal
Packaging Speed	4–8 cycles/min
Bottom Film Thickness	≤0.8 mm
Bottom Film Width	522 mm
Top Film Width	485 mm
Maximum Forming Size	500 × 400 mm
Maximum Forming Depth	80 mm
Vacuum / MAP Function	Available
Power Supply	AC 380V, 50Hz, 3 Phase
Rated Power	15 kW
Air Consumption	650 L/min
Air Pressure	≥0.6 MPa
Loading Area Length	≥1.5 m
Overall Dimension	6000 × 1200 × 1760 mm
Machine Weight	2200 kg

Process Description

Film Feeding
↓
Thermoforming Packaging Tray
↓
Product Loading
↓
Vacuum / MAP Treatment
↓
Heat Sealing
↓
Automatic Cutting
↓
Finished Product Output

Main Features

• The Thermoforming Vacuum Packaging Machine integrates forming, sealing, and cutting into one automated system.

• Vacuum packaging technology improves freshness preservation for meat and food products.

• MAP capability provides flexible packaging solutions for different food applications.

• Stainless steel construction ensures hygienic and durable operation.

• Automatic film feeding improves production stability.

• Precise temperature control guarantees reliable sealing quality.

• Customized molds support different package sizes and shapes.

• High-speed operation increases industrial packaging efficiency.

• Intelligent PLC control simplifies machine operation.

• Strong sealing performance reduces leakage and contamination risks.

• Suitable for fresh meat, processed meat, poultry, seafood, pasta, and ready meals.

• The modular design allows integration with complete food production lines.

Why Choose This Equipment

✓ The Thermoforming Vacuum Packaging Machine provides a complete automated packaging process for industrial food production.

✓ The machine improves meat packaging efficiency with reliable vacuum sealing technology.

✓ The system reduces labor requirements and increases production capacity.

✓ Vacuum and MAP functions support different food preservation requirements.

✓ The hygienic stainless steel structure meets food processing standards.

✓ Customized molds allow packaging of various product sizes.

✓ Stable operation ensures consistent package quality during long production cycles.

✓ The equipment can integrate with meat processing and ready meal production lines.

Application Scenarios

1. Meat Processing Industry

The Thermoforming Vacuum Packaging Machine provides efficient vacuum and MAP packaging solutions for fresh meat, beef, pork, lamb, and processed meat products, helping extend shelf life and maintain product quality.

2. Poultry Processing Plants

The machine is suitable for chicken, turkey, and other poultry packaging applications, delivering hygienic sealing performance and reliable protection during storage and transportation.

3. Seafood Processing Factories

Designed for fish, shrimp, squid, and other seafood products, the equipment helps reduce oxidation and preserve freshness through vacuum and modified atmosphere packaging technology.

4. Ready Meal and Central Kitchen Production

The machine supports large-scale packaging of prepared meals, meal kits, and convenience foods, improving production efficiency and ensuring consistent package appearance.

5. Pasta and Noodle Manufacturing

Suitable for fresh pasta, ravioli, noodles, and other flour-based products, providing professional packaging solutions for retail sales and food distribution.

6. Frozen Food Processing Industry

The equipment is widely used for frozen meat, dumplings, frozen pasta, and convenience foods, offering strong sealing performance and improved product protection during freezing and logistics.

Production Benefits

Extended Product Shelf Life

Vacuum and MAP technologies reduce oxygen exposure and help preserve freshness.

Improved Packaging Appearance

Creates uniform and professional packages suitable for retail markets.

Reduced Labor Cost

Automatic operation reduces manual packaging requirements.

Higher Production Efficiency

Continuous operation supports large-volume food manufacturing.

Better Product Protection

Strong sealing prevents leakage and improves transportation safety.

FAQ

Q1: What products can this Thermoforming Vacuum Packaging Machine package?

It can package meat, poultry, seafood, pasta, noodles, ready meals, and other food products.

Q2: Is it suitable for meat processing factories?

Yes. It is widely used for fresh meat, processed meat, sliced meat, and poultry packaging.

Q3: What is the difference between vacuum and MAP packaging?

Vacuum packaging removes air, while MAP replaces air with protective gas to extend shelf life.

Q4: Can the machine package fresh pasta products?

Yes. It is suitable for fresh pasta, ravioli, noodles, and other flour-based foods.

Q5: What packaging materials can be used?

It supports flexible films and thermoforming packaging materials.

Q6: Can package sizes be customized?

Yes. Different molds can be designed according to product dimensions.

Q7: Is the machine suitable for continuous production?

Yes. It is designed for industrial food factories requiring continuous operation.

Q8: What material is used for the machine structure?

The machine is manufactured with food-grade stainless steel for hygiene and durability.

Q9: Can it connect with other production equipment?

Yes. It can integrate with conveyors, weighing systems, labeling machines, and processing lines.

Q10: How does vacuum packaging benefit meat products?

It reduces oxidation, improves preservation, and helps maintain product quality during storage and transportation.
