Permanent Magnetic Lifters 100kg to 5000kg Steel Plate / Cylindrical Magnetic Lifter Permanent Magnetic Chuck Powerful Lifting Magnets

Add to wishlist
Compare

NOTE: Prices may vary by product model and material.

  • Cold-state power(kw):2.6-41.6
  • Lifting capacity: 100kg-5000kg
  • Color: yellow/orange
  • Rated voltage: according to client’s requirement
  • We can make products according to customer requirements.

$84.00

Compare

Models of the Permanent Magnetic Lifters

Model Lifting capacity Dimension Net weight
Steel plate Cylindrical Length Width Height Handle
PML-100 100kg 50kg 92mm 62mm 69mm 155mm 3.2kg
PML-200 200kg 100kg 130mm 65mm 69mm 155mm 5.4kg
PML-400 400kg 200kg 160mm 95mm 95mm 200mm 11kg
PML-600 600kg 300kg 210mm 120mm 120mm 230mm 20kg
PML-1000 100kg 500kg 260mm 150mm 140mm 255mm 40kg
PML-1500 1500kg 750kg 340mm 150mm 140mm 255mm 48kg
PML-2000 2000kg 1000kg 400mm 170mm 170mm 320mm 74kg
PML-3000 3000kg 1500kg 440mm 170mm 170mm 380mm 105kg
PML-5000 5000kg 2500kg 600mm 230mm 215mm 600mm 248kg

Features & Avantage

  1. Crane electromagnetic chuck adopts fully enclosed structure and has good moisture resistance.
  2. Our crane electromagnetic is optimized by computer, the structure is reasonable, and the energy consumption is low.
  3. The excitation coil is treated by special process to improve the electrical and mechanical properties. The insulation material has a heat resistance grade of C and a long service life.
  4. Different structures and parameters are adopted for different items to be sucked, which can widely meet user requirements.
  5. The high-temperature electromagnet adopts a unique heat insulation method, the sucked material temperature from former 600 ºC to present 700 ºC, expanding the applicable scope of the electromagnet.
  6. Easy installation, operation and maintenance.
