Plastic Chemical Barrel Crusher Machine 20HP-75HP Recycling Crusher for Plastic Bottles Barrels Extrusion Injection Molding Blow Molding
NOTE: Prices may vary by product model and material.
Application Range
GB series granulator is especially efficient for hollow barrel, PET barrel, paint barrel, chemical barrel and so on.
Special patent front-positioning blade design especially for large hallow material like bottles and barrels, the rotary blades and stationary blades are settled with a V-shaped angle leading the crushing subject into rotary center, with large cutting angle, excellent efficiency, even flake output and less powder occurred.
$13,800.00
CompareMODELS OF THE Plastic Chemical Barrel Crusher Machine
| Model | GB20HP | GB30HP | GB50HP | GB75HP |
| Grinding Chamber | 530mm×400mm | 530mm×400mm | 830mm×520mm | 1100mm×740mm |
| Power | 15KW | 22KW | 37.5KW | 55KW |
| 20HP | 30HP | 50HP | 75HP | |
| Grinding Capacity | 350KG/H-550KG/H | 400KG/H-550KG/H | 750KG/H-1080KG/H | 800KG/H-1200KG/H |
| Stationary Cutter | 2 | 2 | 4 | 4 |
| Rotary Cutter | 3 | 3 | 6 | 9 |
| Mesh Size | Φ14mm | Φ14mm | Φ16mm | Φ16mm |
| Barrel Volume | 30L | 30L | 100L | 200L |
| Barrel Size(mm) | Φ330mm*490mm | Φ330mm*490mm | Φ420mm*780mm | Φ600mm*1000mm |
| Dimension (L×W×H) | 1430×1120×1930mm | 1430×1120×1930mm | 2000×1610×2690mm | 2450×1940×3460mm |
New Cutter Design
The rotary blades and stationary blades are settled as a V-shaped angle. This angle can make better cutting. The granules are evenly cut and less powder is caused.
Durable Cutter
Blades are made of high-strength alloy tool steel, with high hardness, good abrasion resistance, and long durability.
Adopted hexagon socket screw installation way of the blades and strong wear resistance.
Material: CR12MOV, hardness in 57-59°
Self-Aligning Bearings
With high-quality self-aligning bearings with excellent lifetime running.
Chamber Wall Thickness
Chamber wall thickness 20~50mm, more stable in crushing process due to better load-bearing, hence with higher durability.
Auto Collecting System
With auto collecting blower for easy and efficient operations;
With cyclone to separate material and air for easy collecting;
With dust collecting bag for handy cleaning;
