Caliber range:
|
DN3-DN3000 (DN3\DN4 is flange clamping type)
|
Lining type:
|
Polychloroprene rubber, PTFE, F46, PFA, silicon
fluoride, polyurethane rubber |
Electrode type:
|
316L, Ha B, Ha C, titanium, tantalum, platinum-iridium
alloy, stainless steel tungsten carbide |
Pressure range:
|
0.6~42Mpa (high pressure needs to be customized)
|
Temperature resistance:
|
-25~80℃
|
Accuracy:
|
±0.5%, can be customized ±0.3%, ±0.2%
|
Protection level:
|
Sensor IP65\IP67\IP68 (optional), converter IP65
|
Output type:
|
Frequency, pulse, 4-20mA, RS485, Modbus protocol, Hart protocol (optional),
Profibus DP (optional), |
Power supply:
|
85~250V, 45~63Hz, 20VDC — 36VDC
|
Temperature sensor :
|
1 pair ,PT1000
|
Liner material
|
Applications
|
|
PTFE:
|
1.The most steadiest material in plastics which is resistance to boiling hydrochloric acid ,vitriol and aqua regia as well as
strong and organic impregnates. 2.Not be perfect in abrasion resistance |
Strong corrosive mediums such as strong acid and alkali
|
PTF:
|
Having the same abration resistance with PTFE .Having strong ability of load pressure resistance.
|
Applicable in state of load pressure
|
F46:
|
1. Having the same abration resistance with PTFE.
2.Resistance for low abration.3.Having strong resistance to load pressure |
1.The same as PTFE
2.Applicable in medium of low abrasion |
Neoprene:
|
Be of good elasticity ,retractility and abration resistance 2.Be resistance to low acid ,alkali and salt but not for oxidation
medium |
Water,sewage and slurry ,mineral serosity of low abration.
|
Neoprene:
|
1.Be good of abration resistibility (equal to 10 times of caoutchouc)
2.Not be perfect in acid/alkali resistance 3.Can;t be used for water mixted with organic impregnants |
Applicable in mineral serosity,slurry and coal slurry of high abration.
|
