Automatic Navigation Pallet Jack Workshop High Efficiency

Add to wishlist
Compare

1.Workshop material distribution, reducing workshop aisle operators, and creating a green chemical factory.
2.The stacking of factory warehouses makes warehousing more standardized and orderly, fully improving space utilization and transportation efficiency.

$38,000.00

Compare

Characteristic
1
 Pallet Jack Model
unit
PJ10
PJ16
2
Power type
Electric
3
Driving type
Automatic
4
Navigation mode
Laser
5
Rated load
Q kg
1000
1600
6
Load center
C mm
600
600
7
Wheelbase
Y mm
875
875
Wheel
8
Tyre
PU
9
Drive wheel size
mm
Φ230*75
Φ230*75
10
Bearing wheel size
mm
Φ80*40
Φ80*40
11
Auxiliary wheel size
mm
Φ115*55
Φ115*55
12
Front track width
b11 mm
500
350/400/510
Size
13
Total height
h1 mm
1750
1750
14
Lifting height
h3 mm
1600
1600
15
Fork height (at lowest)
h5 mm
85
85
16
Total length
L1 mm
1625
1625
17
Overall width
b1 mm
921
921
18
Fork size
s/e/l mm
180X55X1150
180X55X1150
19
Fork outer width
b3 mm
520/570/670
520/570/671
20
Minimum ground clearance
m mm
40
40
21
Right angle stacking channel width,Tray 1000x1200mm
Ast mm
1850
1850
22
Right angle stacking channel width,Tray 800x1200mm
Ast mm
1650
1650
23
Turning radius
Wa mm
1150
1150
Performance
24
Driving speed no load/full load
m/s
1.5/1.0
1.0/0.8
25
Lifting speed no load/full load
mm/s
150/100
150/90
26
Lowering speed no load/full load
mm/s
100/130
100/140
27
Maximum climbing capacity empty/full load
%
4/3
4/3
28
Braking method
Electromagnetic brake
Motor
29
Drive motor power (s2.60 minutes)
kw
1.2
1.5
30
Increase motor power (s3,15%)
kw
2.2
3
31
Steering motor power (s2, 10 minutes)
kw
0.165
0.165
32
Lithium battery voltage/capacity (5-hour discharge rate)
V/Ah
24/140
24/165
33
Lithium battery weight
kg
55
60
Others
34
Self weight (including battery)
kg
680
700
35
Steering mode
Electronic steering
36
Charging method
Automatic
37
Battery life
h
6 Hours
38
Vehicle noise according to en12503
dB(A)
<70
39
Communication mode
wifi/5G
40
Stop accuracy
mm
±10mm
41
Color
Customized
42
Display
●Standard
43
Manual operation
○NONE
Safety
44
Safety protection function
○NONE
45
Front laser obstacle avoidance
○NONE
46
Left and right laser obstacle avoidance
●Standard
47
Tachograph
○NONE
48
Vehicle body surround collision strip detection
●Standard
49
Tray in place detection
●Standard
50
Pallet identification adjustment
○NONE
51
Fork tooth detection (collision and non-contact)
●Standard
52
Emergency stop button
○NONE
53
Audible and visual alarm
●Standard
54
Cargo inspection
●Standard

1.Workshop material distribution, reducing workshop aisle operators, and creating a green chemical factory.
2.The stacking of factory warehouses makes warehousing more standardized and orderly, fully improving space utilization and transportation efficiency.
