Professional IP68 Double-glass Bifacial Sun Production Panel Solar Cells
| Brand Name: | CanadianSolar |
| Model Number: | CS3Y-MB-AG |
| Cell size: | 166mmx166mm |
| Type: | PERC, Half Cell, Bifacial, Double-glass, high power |
| Panel Dimensions: |
2260 X 1048 X 32 mm |
$197.00 – $203.00
Compare
SOLAR PANELS PRODUCT SPECIFICATIONS
|
MECHANICAL DATA
|
ELECTRICAL DATA
|
|||
|
Cell Type
|
Mono-crystalline
|
Operating Temperature
|
-40°C ~ +85°C
|
|
|
Cell Arrangement
|
156 [2 X (13 X 6) ]
|
Max. System Voltage
|
1500 V (IEC/UL) or 1000 V (IEC/UL)
|
|
|
Dimensions
|
2260 ˣ 1048 ˣ 32 mm (89.0 ˣ 41.3 ˣ 1.26 in)
|
Module Fire Performance
|
TYPE 29 (UL 61730) or CLASS C (IEC61730)
|
|
|
Weight
|
29.9 kg (65.9 lbs)
|
Max. Series Fuse Rating
|
25 A
|
|
|
Front / Back Glass
|
2.0 mm heat strengthened glass
|
Application Classification
|
Class A
|
|
|
Frame
|
Anodized aluminium alloy
|
Power Tolerance
|
0 ~ + 10 W
|
|
|
J-Box
|
IP68, 3 diodes
|
Power Bifaciality
|
70%
|
|
|
Cable
|
4.0 mm² (IEC), 12 AWG (UL)
|
TEMPERATURE CHARACTERISTICS
|
||
|
Cable Length (Including Connector)
|
410 mm (16.1 in) (+) / 290 mm (11.4 in) (-) or customized length
|
Temperature Coefficient (Pmax)
|
-0.35 % / °C
|
|
|
Connector
|
T4 series or H4 UTX or MC4-EVO2
|
Temperature Coefficient (Voc)
|
-0.27 % / °C
|
|
|
Per Pallet
|
33 pieces
|
Temperature Coefficient (Isc)
|
0.05 % / °C
|
|
|
Per Container
|
(40′ HQ) 660 pieces or 528 pieces (only for US)
|
Nominal Module Operating Temperature
|
41 ± 3°C
|
|
Precautions for unpacking the solar panel:
· The components are placed vertically in the box.
· Before unpacking, please place the whole pallet assembly on a flat place.
· To prevent the operator’s hand from being injured, please wear gloves for operation.
· Do not disassemble the entire packing box until all components are taken out.
· When the components are taken out of the box, two workers are required to operate with both hands at the same time.
· If the packaging or components are damaged during unpacking, please take photos and contact the sales/customer service personnel of Canadian Solar at the first time. If the customer fails to disassemble according to the prescribed steps and causes personal or property damage, our company will not bear any responsibility.
