Trinasolar 545w 550w 555w Trina Tsm-de19 Solar Energy Panel Half Cell Trina Solar Panel Price
High power up to 550w
Up to 21.3% module efficiency with high density interconnect technologyMulti-busbar technology for better light trapping effect, lower series resistanceand improved current collection
High reliability
Ensured PID resistance through cell process and module mnaterial control Resistant to harsh environmments such as salt, ammmmonia, sand, high temperatureand high humidity areas
Mechanical perforrance up to 5400 Pa positive load and 2400 Pa negative load
$160.00 – $278.00
CompareUp to 21.3% module efficiency with high density interconnect technologyMulti-busbar technology for better light trapping effect, lower series resistanceand improved current collection
High reliability
Ensured PID resistance through cell process and module mnaterial control Resistant to harsh environmments such as salt, ammmmonia, sand, high temperatureand high humidity areas
Mechanical perforrance up to 5400 Pa positive load and 2400 Pa negative load
|
MECHANICAL SPECIFICATIONS
|
|
|
Cell Type
|
Monocrystalline
|
|
Weight
|
27.8 kg (61.3 lb)
|
|
Dimensions
|
2278×1134×35 mm (89.69×44.65×1.38 inches)
|
|
Cables
|
Photovoltaic Technology Cable 4.0mm2 (0.006 inches2),
Portrait: N 280mm/P 280mm(11.02/11.02inches) Length can be customized |
|
Glass
|
3.2 mm (0.13 inches), High Transmission, AR Coated Heat Strengthened Glass
|
|
Packaging
|
31pcs/box, 620pcs/40 Container
|
|
ELECTRICAL SPECIFICATIONS（STC Testing Condition）
|
|||||
|
Peak Power Watts-PMAX(Wp)*
|
530
|
535
|
540
|
545
|
550
|
|
Maximum Power Voltage-VMPP (V)
|
40.7
|
40.9
|
41.2
|
41.4
|
41.6
|
|
Maximum Power Current-IMPP(A)
|
13.03
|
13.07
|
13.12
|
13.16
|
13.21
|
|
Open Circuit Voltage-VOC (V)
|
48.9
|
49.1
|
49.3
|
49.5
|
49.8
|
|
Short Circuit Current-ISC(A)
|
13.82
|
13.87
|
13.92
|
13.97
|
14.02
|
|
Module Efficiency η m(%)
|
20.5%
|
20.7%
|
20.9%
|
21.1%
|
21.3%
|
|
Power Tolerance-PMAX(W)
|
0~5%
|
||||
|
Temprature Coefficient (Pmax)
|
-0.34%/℃
|
||||
|
Temprature Coefficient (Voc)
|
-0.25%/℃
|
||||
|
Temprature Coefficient (Isc)
|
0.04%/℃
|
||||
| Specification: | 530W, 540W, 550W |
|---|
