Best Trinasolar Panel Panneaux Solaires Vertex Bifacial 665w 660w 655w 650w Double Glass Solar Panel Half Cut In The World

Add to wishlist
Compare

higher customer value
·Effectively reduce the cost of system BOS: achieve lower cost of electricity and improve project yield
Lower power attenuation value in the first year and year by year
The product is compatible with mainstream system design
The maximum power is increased to 670W
·Application of 210mm large silicon wafer technology and half-cut module technology
Application of dense packing technology, module efficiency increased to 21.6%
Application of multi-busbar (MBB) technology to effectively improve optical utilization and reduce internal current consumption
high reliability
·Application of innovative non-destructive cutting technology to reduce the risk of hidden cracks.
Improve the anti-PID performance through battery process optimization and material control.
Passed the mechanical load test of 5400 Pa on the front and 2400 Pa on the back
· Resistant to salt spray, dust, ammonia and other harsh environments
High power generation performance
·Excellent IAM and weak light response performance verified by a third party
Lower temperature coefficient (-0.34%) and lower operating temperature bring more power generation
·Unique version design brings stronger anti-shadow blocking ability

$243.00 – $250.00

Compare
Electrical Characteristics STC
Peak Power Watts-PMAX (Wp)*
645
650
655
660
665
Power Tolerance-PMAX (W)
0~+5
Maximum Power Voltage-VMPP (V)
37.5
37.7
37.9
38.1
38.3
Maximum Power Current-IMPP (A)
17.23
17.27
17.31
17.35
17.39
Open Circuit Voltage-VOC (V)
45.3
45.5
45.7
45.9
46.1
Short Circuit Current-ISC (A)
18.31
18.35
18.4
18.45
18.5
Module E_x005fciency η m (%)
20.8
20.9
21.1
21.2
21.4
MECHANICAL DATA
Cell Type
Monocrystalline
No. of cells
132 cells
Module Dimensions
2384×1303×33 mm (93.86×51.30×1.30 inches)
Weight
38.3 kg (84.4 lb)
Front Glass
2.0 mm (0.08 inches), High Transmission, AR Coated Heat Strengthened Glass
Encapsulant material
EVA/POE
Back Glass
2.0 mm (0.08 inches), Heat Strengthened Glass (White Grid Glass)
Frame
33 mm(1.30 inches) Anodized Aluminium Alloy
J-Box
IP 68 rated
Cables
Photovoltaic Technology Cable 4.0mm2 (0.006 inches2),
Portrait: 350/280 mm(13.78/11.02 inches)
Length can be customized
Connector
MC4 EVO2 / TS4*
PACKAGING CONFIGUREATION
Modules per box
33 pieces
Modules per 40’ container
594 pieces
SKU: N/A Category: Tag:
Specification:

650W, 655W, 660W, 665W

Based on 0 reviews

0.0 overall
0
0
0
0
0

Be the first to review “Best Trinasolar Panel Panneaux Solaires Vertex Bifacial 665w 660w 655w 650w Double Glass Solar Panel Half Cut In The World”

There are no reviews yet.
