Hot Sale Factory Direct Price Battery Storage Inverter Goodwe GW5048-ESA solar inverters
Wiring Pretreatment
Integrated UPS function
Battery capacity can be expanded
Integrated isolating switch
$4,750.00
CompareGoodWe ESA series single-phase energy storage all-in-one machine aims to provide you with an intelligent and convenient all-in-one optical storage solution. With advanced modular design, it integrates single-phase energy storage inverters, switch boxes, batteries and battery cabinets and other important components.
It is extremely convenient to install and use, intelligently manages and controls multiple working modes, and flexibly realizes power dispatching, storage and power load management, helping you easily become the master of power.
At the same time, the compact and elegant appearance design perfectly integrates with modern homes, and the IP65 protection level of the inverter is suitable for various indoor and outdoor installation requirements.
|
Battery cabinet parameters
|
||||
|
Weight (KG)
|
37
|
|||
|
Outer Size
|
516*1205*280
|
|||
|
Installation
|
Hanging
|
|||
|
Protect Class
|
IP54
|
|||
|
Technical Parameter
|
GW5048-ESA
|
|||
|
Battery input parameters
|
||||
|
Battery Type
|
Li-ion
|
|||
|
Rated Battery Voltage（V)
|
48
|
|||
|
Battery Voltage Range （V)
|
40~60
|
|||
|
Max Continuous Charge Current （A)
|
90
|
|||
|
Maximum Continuous Discharge Current （A)
|
100
|
|||
|
Maximum Charging Power （W)
|
4600
|
|||
|
Maximum Discharge Watt （W)
|
4600
|
|||
|
Maximum Number of Connected Batteries
|
4
|
|||
|
PV Input Parameters
|
||||
|
Max. Input Power (W）
|
6500
|
|||
|
Max. Input Voltage (V）
|
580
|
|||
|
MPPT Range (V)
|
125~550
|
|||
|
Start-up Voltage (V)
|
125
|
|||
|
Rated Output Voltage (V)
|
360
|
|||
|
Max. Input Current (A)
|
14
|
|||
|
Mac. Short Current (A)
|
17.5
|
|||
|
No. of MPPT Rackers
|
2
|
|||
|
No. of Input Strings per Tracker
|
1
|
|||
|
On-grid Output Parameters
|
||||
|
Rated grid-Connected Output Apparent Power （VA）
|
5000
|
|||
|
Maximum grid-Connected Output Apparent Power （VA）
|
5000
|
|||
|
PV （VA）
|
9200
|
|||
|
Rated Power Output（V)
|
230
|
|||
|
Frequency of output voltage （Hz）
|
50
|
|||
|
Maximum grid-tied Output Current（A)
|
22.8
|
|||
|
Max Input Current （A)
|
40
|
|||
|
Power Factor
|
~1
|
|||
|
Output Current THD
|
<3%
|
|||
|
Off-grid Output Parameters
|
||||
|
Off-grid Apparent Power Rating （VA）
|
4600
|
|||
|
Maximum Output Apparent Power （VA）
|
4600
|
|||
|
Maximum Output Current （A)
|
20
|
|||
|
Rated output voltage （V)
|
230
|
|||
|
Rated output voltage frequency （Hz）
|
50
|
|||
|
Total Voltage Waveform Distortion Rate
|
<3%
|
|||
|
Max. Efficiency
|
97.6%
|
|||
|
Battery side ，AC side Maximum Efficiency
|
94.0%
|
|||
|
Basic Parameter
|
||||
|
Operating Temperature Range (℃)
|
-25~+60
|
|||
|
Relative Temperature
|
0~95%
|
|||
|
Maximum Operating Altitude (m)
|
3000
|
|||
|
Cooling Model
|
Nature
|
|||
|
HMI
|
LED，APP
|
|||
|
BMS Communication
|
RS485,CAN
|
|||
|
Meter Communication
|
RS485
|
|||
|
Monitor Mode
|
WiFi
|
|||
|
Weight (KG)
|
44
|
|||
|
Size (mm)
|
516*832*290mm
|
|||
|
Topology
|
Unshielded
|
|||
|
Night Power Expenditure
|
<10
|
|||
|
Protection Class
|
IP65
|
|||
|
Installation
|
Hanging
|
|||
| Specification | 530w, 535w, 545w |
|---|
