PE Film Sleeve Wrapping Manufacturer for Beverage Packaging

PE Film Sleeve Wrapping Product Introduction

PE Film Sleeve Wrapping Manufacturer for Beverage Packaging is an intelligent automatic shrink packaging system developed for beverage manufacturers requiring reliable multipack packaging, high production efficiency, and strong transport protection. The machine combines automatic bottle arrangement, grouping, sleeve film feeding, PE film wrapping, heat tunnel shrinking, shaping, and finished product output into one integrated packaging platform.

Specially engineered for bottled beverage production lines, the equipment is suitable for mineral water, purified water, carbonated drinks, juice, tea beverages, energy drinks, dairy products, beer, canned beverages, and liquid food packaging operations. Compared with traditional carton packaging methods, PE sleeve wrapping significantly reduces packaging cost, lowers material consumption, improves packaging flexibility, and provides strong bundle stability during storage, transportation, and retail display.

Industry Pain Points

• Beverage manufacturers require high-speed multipack packaging capability.

• Manual grouping and wrapping reduce line efficiency.

• Packaging instability causes bottle movement during transportation.

• Traditional carton packaging increases material costs.

• Production lines require continuous automatic packaging performance.

• Multiple bottle sizes create difficult equipment adjustments.

• Increasing labor expenses affect packaging profitability.

• Beverage plants require attractive retail-ready packaging.

Our Solution

Our PE Film Sleeve Wrapping System provides automatic product conveying, intelligent bottle grouping, sleeve film wrapping, shrink tunnel heating, cooling, and finished package discharge in one complete beverage packaging solution.

The system supports multiple packaging formats, different bottle diameters, customizable sleeve configurations, and seamless integration with beverage filling, labeling, coding, and palletizing lines.

System Overview

The equipment combines bottle infeed, automatic arrangement, product grouping, PE sleeve film application, thermal shrink processing, package shaping, cooling, inspection, and output conveying into one high-efficiency packaging system.

Built for industrial beverage production environments, the machine delivers stable shrink quality, strong package integrity, high production output, and continuous automatic packaging performance.

Process Description

Filled bottles or cans are automatically conveyed into the grouping section, where products are aligned, counted, and arranged according to predefined packaging formats. The system performs synchronized sleeve film feeding and wrapping to create secure bundle packaging around grouped beverage products.

Wrapped products enter the shrink tunnel for controlled thermal shrinking, ensuring tight film conformity, stable bundle formation, and professional package appearance. Finished packages then pass through cooling, shaping, inspection, and discharge stages before transfer to warehousing, palletizing, or distribution operations.

Why Choose This Equipment

• Designed for beverage multipack shrink packaging.

• High-speed automatic sleeve wrapping technology.

• Reduced packaging material consumption.

• Strong package stability for transportation protection.

• Suitable for bottles, cans, and beverage containers.

• Intelligent PLC touchscreen control.

• Flexible packaging layout compatibility.

• Continuous industrial production capability.

• Easy production line integration.

• Low operating and maintenance costs.

Technical Specifications

Item	Specification
Product Name	PE Film Sleeve Wrapping Manufacturer for Beverage Packaging
Product Category	Shrink Wrapping
Machine Type	Automatic PE Sleeve Shrink Wrapping Machine
Suitable Products	Bottled Water, Juice, Beer, Soft Drinks, Dairy Products, Cans
Packaging Type	Sleeve Shrink Packaging
Product Format	Bottles / Cans / Containers
Packaging Layout	2×2 / 3×2 / 4×3 / 6×4 / Custom
Production Speed	10–60 Packs/Min
Output Capacity	Up to 7200 Bottles/Hour
Bottle Diameter Range	45–120 mm
Bottle Height Range	80–350 mm
Film Material	PE Shrink Film
Film Thickness	30–120 μm
Film Width	250–700 mm
Sleeve Feeding System	Automatic Servo Film Feeding
Grouping System	Automatic Product Collation
Shrink Method	Hot Air Tunnel Shrinking
Tunnel Temperature	Adjustable 120–260°C
Heating Type	Electric Heating
Cooling Method	Forced Air Cooling
Control System	PLC + Touchscreen HMI
Drive Type	Servo Motor + Frequency Converter
Sensor System	Photoelectric Detection
Air Pressure	0.5–0.8 MPa
Air Consumption	250–600 L/min
Voltage	220V / 380V / 415V / 50–60Hz
Installed Power	10–35 KW
Machine Frame Material	Carbon Steel / SUS304 Optional
Conveyor Height	Adjustable
Operation Mode	Fully Automatic
Safety System	Safety Guards + Emergency Stop
Optional Functions	Coding / Labeling / Inspection / Palletizing
Customization	Supported

Capacity / Output

10–20 packs per minute for standard beverage packaging applications.

20–40 packs per minute for medium-speed bottled beverage production lines.

40–60 packs per minute for customized high-speed beverage shrink packaging systems depending on bottle dimensions, grouping configuration, and film specifications.

Heavy-duty customized solutions are available for large beverage factories and mineral water production plants.

Main Features

• Automatic bottle and can conveying.

• Intelligent bottle grouping technology.

• Servo-controlled sleeve film feeding.

• High-efficiency PE film wrapping system.

• Industrial shrink tunnel heating module.

• Stable cooling and package shaping section.

• PLC smart touchscreen operation.

• Low film waste design.

• Continuous automatic packaging capability.

• Quick product format changeover.

• High packaging consistency.

• Easy maintenance structure.

Engineering Advantages

• Advanced servo synchronization technology ensures accurate bottle positioning, stable film transfer, and consistent shrink wrapping performance.

• Optimized heat circulation design improves shrink uniformity, package appearance, and energy efficiency.

• Heavy-duty industrial frame structure supports long-hour continuous beverage packaging production.

• Flexible engineering architecture supports multiple bottle shapes, container sizes, packaging layouts, and line configurations.

• Intelligent motion control reduces downtime, improves operational stability, and increases production efficiency.

• Optional smart modules including coding, inspection, robotic palletizing, and data monitoring support packaging automation upgrades.

Application Scenarios

• Mineral water bottle multipack packaging.

• Carbonated drink and soft beverage shrink wrapping.

• Beer bottle and canned beverage sleeve packaging.

• Juice, tea beverage, and dairy product bundle packaging.

• End-of-line beverage production packaging systems.

• Export packaging and warehouse distribution operations.

Industry Applications

• Beverage Industry — Automatic sleeve shrink packaging for bottled water, juice, tea, soda, and dairy drinks.

• Beer Industry — Multipack packaging for beer bottles, beer cans, and alcoholic beverage products.

• Food & Liquid Industry — Packaging solutions for liquid food containers and consumer beverage products.

• FMCG Industry — High-speed secondary packaging for fast-moving consumer goods.

• Contract Packaging Industry — Flexible shrink packaging services for OEM and co-packing facilities.

• Warehouse & Logistics Industry — Stable bundle packaging for transport and distribution operations.

FAQ

1. Which products can this machine package?

The equipment is suitable for bottled water, beer, juice, carbonated drinks, dairy beverages, canned products, and other beverage containers.

2. Which film material does the system use?

The machine is designed for PE shrink film packaging applications.

3. Can different bottle sizes be packaged?

Yes. Adjustable settings and customized tooling support multiple bottle diameters, heights, and packaging formats.

4. Is the equipment suitable for high-speed production lines?

Yes. The system supports medium- and high-speed beverage packaging operations with stable continuous performance.

5. Can the machine connect with filling lines?

Yes. The equipment can integrate with beverage filling, labeling, coding, conveyor, and palletizing systems.

6. Which packaging layouts are supported?

2×2, 3×2, 4×3, 6×4, and customized packaging configurations are supported.

7. Is customization available?

Yes. Voltage, speed, tunnel size, bottle format, control configuration, and optional functions can be customized.

8. Which industries commonly use this equipment?

Beverage, beer, bottled water, dairy drink, FMCG, and contract packaging industries.

9. What advantages does PE sleeve packaging provide?

Lower packaging cost, reduced material use, improved transport stability, and strong retail presentation.

10. Does the system support automatic operation?

Yes. Conveying, grouping, film feeding, shrinking, cooling, and discharge functions operate automatically.
