40 us gallons (151 liters) Stainless Steel Mixtanks Mixing Tank Manufacturers
- Size and geometry
- Material viscosity
- 100% sanitary interior welds.
- Ease of cleaning (CIP) for fast and efficient cleaning operations
- Mix impeller size and quantity
- Mix with a set speed or variable speed according to your requirements
- Mix with impeller motion in one direction or agitating according to your requirements
$2,287.00
ComparePreparation Vessels, Reactor & Tank :
Design compliance with cGMP
Capacity up to 25,000 Liter.
Product Contact AISI 316L .
Vertical & Horizontal design
Atmospheric, Vacuum or Pressure Operation.
Plain, Jacket for heating & cooling.
Option for Heating by steam, hot water or tharic fluid oil & Electric heater.
Thermal Insulated.
Mechanicals or Electro polishing of internal surface.
Welded, flanged or hinged type cover
Integrated Cleaning in Place-CIP.
Sterilizing In Place-SIP as an Option.
Option for mounting on legs or flange.
Portable execution on request.
Validation protocols & Instrumentation celebration.
Variable Speed Agitation :
Agitator can be top or bottom driven or magnetically driven.
Propeller type, Anchor type provided with High speed disperser or rotor-stator homogenizer.
Single or double mechanical seal.
Automation available, appropriate for the intended process function, including CIP and SIP :
Controls of all function by PLC Controls with HMI Touch screen.
Level controls by means of capacitance probe or electronic load cells.
Digital indication and controls of all process parameters for Process time, agitator speed, temperature, pressure & level.
| Product Parameters | ||||||
| Capacity | Motor | Jacket | Inner-Wall | Outer Package | Jacket | Insulation |
| L | Power | Pressure | Thickness | Thickness | Thickness | |
| 100 | 0.75 kw | 0.09 Mpa | 3 mm | 0.6 mm | 3 mm | Rock Wool Insulation |
| 200 | 0.75 kw | 0.09 Mpa | 3 mm | 0.6 mm | 3 mm | |
| 300 | 0.75 kw | 0.09 Mpa | 3 mm | 0.6 mm | 3 mm | |
| 500 | 0.75 kw | 0.09 Mpa | 3 mm | 0.6 mm | 3 mm | |
| 600 | 0.75 kw | 0.09 Mpa | 3 mm | 0.6 mm | 3 mm | |
| 800 | 0.75 kw | 0.09 Mpa | 3 mm | 0.6 mm | 3 mm | |
| 1000 | 1.1 kw | 0.09 Mpa | 3 mm | 0.6 mm | 3 mm | |
| 1500 | 1.1 kw | 0.09 Mpa | 3 mm | 0.6 mm | 3 mm | |
| 2000 | 1.5 kw | 0.09 Mpa | 3 mm | 0.6 mm | 3 mm | |
Tanks without cover.
Custom tanks available. Contact us with your request.
