Wire Rope Electric Hoist 0.5T-10T 3/6/9/12M High Quality Electric Hoist Heavy Duty Electric Hoist Crane Wire Rope Pulling With Electric Trolly
NOTE: Prices may vary by product model and material.
- Product Name: Wire Rope Electric Hoist
- Product model: 0.5T-10T 3/6/9/12M
- Product material: bold manganese steel
- Rated power: 380V
- Product features: safe braking, stable operation, high efficiency and convenience, complete specifications
- Scope of application: suitable for docks, factories, bridges, transportation, etc.
$550.00
CompareIt is a small-sized lifting equipment, which can be mounted on all types of cranes,such as gantry crane, overhead crane, jib crane and other special crane to lift all types of material. With a small modification,it can also be used as a winch.What’s more, it can be installed easily with different heights by hand control.
| Model | Wire Rope Electric Hoist | |||||
| Lifting weight (T) | 0.5 | 1 | 2 | 3 | 5 | 10 |
| Lifting height (m) | 6-12 | 6-30 | 6-30 | 6-30 | 6-30 | 9-30 |
| Lifting speed (m/min) | 8(0.8) | 8(0.8) | 8(0.8) | 8(0.8) | 8(0.8) | 7(0.7) |
| Running speed(m/min) | 20 | 20 | 20 | 20 | 20 | 20 |
| Wire rope diameter (m/min) | 4.8 | 7.4 | 11 | 13 | 15.5 | 15.5 |
| The minimum radius of the circular track (m) | 1.5 | 1.5-3.5 | 2-4 | 2-4 | 2-4 | 3-7.2 |
| Lifting motor | ||||||
| Rated power (kw) | 0.8 | 1.5 | 3.0 | 4.5 | 7.5 | 13 |
| Rated speed(r/min) | 1380 | 1380 | 1380 | 1380 | 1400 | 1400 |
| Rated current (A) | 2.2 | 4 | 7 | 10 | 16.5 | 28 |
| Operating motor | ||||||
| Rated power (kw) | 0.2 | 0.2 | 0.4 | 0.4 | 0.8 | 0.8*2 |
| Rated speed(r/min) | 1380 | 1380 | 1380 | 1380 | 1380 | 1380 |
| Rated current (A) | 0.7 | 0.7 | 1.3 | 1.3 | 2.2 | 2.2*2 |
| Machine weight(kg) | 135-195 | 180-255 | 250-360 | 320-440 | 590-800 | 820-1125 |
- Hoist Electric Trolly. Selected materials, safe and secure. Strong braking, stable operation, easy to use.
- Anti-off hook. Quenched forged, not easy to break. The hook can be rotated 360°, and a safety buckle is installed to prevent decoupling.
- Fire limiter. Stable performance and high sensitivity.
- Multi-directional music controller, easy to operate and convenient to use.
