When the PC pinion is installed on the motor shaft, the following points need to be paid attention to:
a. Thoroughly clean the motor drive shaft;
b. Take out the flat key on the motor drive shaft;
c. As shown in the figure below, put the sleeve 1 on the drive shaft. For easier installation, you can heat the sleeve to about 70 – 80C;
d. Install the new flat key 3 on the drive shaft keyway:
e. Referring to the method in c, put the pinion 4 on the drive shaft:
f. Put the gasket 5 and tighten the bolt 6:
g. Take off the rubber cover on the oil seal, this step needs to be careful because the PC has been filled with lubricating oil; h. Install the oil seal 2 and the rest of the motor parts, be careful not to damage the oil seal;
