Powder Screw Feeder Conveyor for Vertical Packing System

Screw Feeder Conveyor Product Introduction

The Screw Feeder Conveyor is a reliable material handling solution designed for continuous transportation of powder, granular, and dry bulk materials. It uses a rotating screw blade inside a tubular conveyor body to move materials smoothly and evenly from the feeding point to the discharge point.

With its compact structure, sealed conveying design, and simple operation, the Screw Feeder Conveyor is widely used in industries requiring efficient and controlled material transfer. It is suitable for handling cement, fly ash, sand, limestone, chemical powder, grain, fertilizer, and other dry materials.

The tubular design helps prevent dust spreading during transportation, making it suitable for environments requiring cleaner production. The conveyor features fewer spare parts, easy installation, and convenient maintenance, reducing downtime and operating costs.

The Screw Feeder Conveyor can be customized according to different conveying distances, installation conditions, and material characteristics. It is an ideal choice for automated production lines, storage systems, mixing equipment, packaging systems, and bulk material processing applications.

Working principle

The Screw Feeder Conveyor operates through a motor-driven spiral screw shaft installed inside a tubular housing. When the screw rotates, the spiral blade pushes powder and granular materials forward along the conveyor tube. The enclosed structure ensures stable transportation while reducing dust leakage and material loss. By controlling the screw rotation speed, the feeding capacity can be adjusted to meet different production requirements.

Equipment Structure

Tubular Conveyor Body

The cylindrical conveyor housing provides a sealed pathway for material transportation and protects the internal screw blade.

Spiral Screw Blade

The spiral blade welded on the center shaft rotates to push materials continuously toward the discharge outlet.

Feeding Port

The feeding inlet allows materials to enter the conveyor smoothly from hoppers, storage tanks, or processing equipment.

Discharge Port

The discharge outlet transfers materials accurately to mixers, storage systems, packaging equipment, or other production machines.

End Bearing Assembly

The bearing structure supports stable screw rotation and improves equipment durability.

Shaft Sealing System

The sealing system helps prevent material leakage and protects internal components during operation.

Support and Connection Components

Flanges and connection sections allow convenient installation, assembly, and maintenance.

Product Parameter Table

Item	Specification
Equipment Type	Tubular Screw Feeder Conveyor
Screw Diameter	238 mm
Outer Diameter	273 mm
Rotating Speed	200 rpm
Maximum Conveying Length	16 m
Inclination Angle	0°–60°
Conveying Capacity	53–70 t/h
Motor Power	11 kW
Conveyor Structure	Tubular Screw Conveying System
Application Material	Powder and Granular Material

Main Features

Compact Tubular Structure

The tubular design provides a compact footprint and allows flexible installation in limited production spaces. It is suitable for horizontal, inclined, and customized conveying layouts.

Efficient Screw Feeding System

The internal spiral blade rotates continuously to push materials forward, ensuring stable and uniform feeding performance.

Sealed Material Transportation

The enclosed conveying structure reduces dust leakage and protects materials from external contamination, improving workplace cleanliness.

Wide Material Compatibility

The Screw Feeder Conveyor can handle various powder and granular materials, including cement, sand, chemical powder, grain, fertilizer, and mineral materials.

Easy Maintenance Design

The simple mechanical structure contains fewer wearing parts, making inspection, maintenance, and replacement more convenient.

Reliable Continuous Operation

The robust screw conveying mechanism provides stable performance for long-term industrial operation.

Flexible Feeding and Discharging

Multiple feeding and discharge points can be designed according to production requirements, improving system flexibility.

Space-Saving Installation

The compact tubular structure requires less installation space compared with many traditional conveying systems.

Reduced Material Loss

The enclosed conveying process helps minimize material leakage, dust emission, and environmental pollution.

Customizable Configuration

The conveyor can be customized according to material properties, conveying capacity, length, and installation conditions.

Application Scenarios

1. Cement Industry

Used for transporting cement powder, fly ash, limestone powder, and other construction materials.

2. Chemical Industry

Suitable for conveying chemical powders, additives, and dry granular materials.

3. Food Processing Industry

Used for transporting flour, grain, starch, sugar, and other dry food ingredients.

4. Mining Industry

Suitable for handling mineral powder, sand, and other bulk materials.

5. Construction Material Production

Used in concrete plants and building material processing systems.

6. Fertilizer Production

Provides stable transportation for fertilizer powder and granular products.

7. Pharmaceutical Industry

Suitable for controlled transportation of dry powder materials.

8. Packaging System

Used as a feeding device for automatic weighing and packaging equipment.

9. Mixing and Blending Line

Provides continuous material supply for industrial mixers.

10. Storage and Transfer System

Used for transferring dry materials between silos, hoppers, and processing equipment.

Suitable Materials

• cement powder
• fly ash
• limestone powder
• sand material
• chemical powder
• fertilizer granule
• grain material
• food ingredient
• mineral powder
• dry bulk material

Advantages of Screw Feeder Conveyor

The Screw Feeder Conveyor provides an efficient and economical solution for dry material transportation. Compared with open conveying systems, its sealed tubular design reduces dust emission and improves environmental conditions. The simple structure makes installation and maintenance easier while ensuring reliable operation.

Its compact size allows installation in various production environments, and the flexible conveying direction makes it suitable for different industrial layouts. With strong adaptability and stable feeding performance, the Screw Feeder Conveyor helps improve automation levels and reduce manual handling requirements.

FAQ

Q1: What materials can the Screw Feeder Conveyor transport?

A1:It can transport powder and granular materials such as cement, sand, chemical powder, grain, and food ingredients.

Q2: Is the Screw Feeder Conveyor suitable for dusty materials?

A2:Yes. The sealed tubular structure helps reduce dust leakage during transportation.

Q3: Can the conveyor length be customized?

A3:Yes. The conveying length, capacity, and installation design can be customized according to requirements.

Q4: Is it easy to maintain?

A4:Yes. The simple structure and limited wearing parts make maintenance convenient.

Q5: Can it be connected with other production equipment?

A5:Yes. It can be integrated with hoppers, mixers, storage systems, and packaging equipment.
