Electric Heating Steam Generator 30-500kg/h Fully Automatic Horizontal Electric Steam Boiler Building Concrete Steam Curing Machine

Add to wishlist
Compare
  • Product name: electric heating steam generator
  • Rated electric power: 24～360KW
  • Rated evaporation capacity: 30～500KG/H
  • Rated working pressure: 0.4/0.7MPa
  • Rated steam temperature: 151C/171°C
  • Water capacity: 23～26.6L

NOTE: Prices may vary by product model and material.

$4,240.00

Compare

Features of Steam Generator

  • Fully automatic intelligent control system: professional manufacturing, high thermal efficiency, convenient and fast.
  • Rapid steam output: high thermal efficiency, cost saving, and continuous improvement of thermal efficiency value.
  • Multiple safety protection devices: There are multiple safety protection devices to ensure the safe operation of the machine.
Rated evaporation kg/h 30 50 65 75 100 130 150 200 250 300 500
Rated evaporation pressure Mpa 0.4/0.7 0.4/0.7 0.4/0.7 0.4/0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7
Rated steam temperature ºC 151/170 151/170 151/170 151/170 170 170 170 170 170 170 170
Rated electric power KW 24 36 48 54 72 96 108 144 180 216 360
Heating tube group number * power Group*kw 2*12 2*18 2*18+12 3*18 4*18 4*24 6*18 8*18 12*15 12*18 16*18
Feed water temperature ºC 20 20 20 20 20 20 20 20 20 20 20
Design Thermal Efficiency % 98 98 98 98 98 98 98 98 98 98 98
Water capacity L 23 23 26.6 26.6 26.6 26.6 26.6 26.6 26.6 26.6 26.6
Shipping weight T 0.09 0.18 0.19 0.2 0.21 0.25 0.28 0.3 0.35 0.4 0.58
