150 kg/h Electric Steam Generator 108 kW for Brewery

Electric heating steam boiler Product Description

The 108 kW 150 kg/h electric heating steam generator is designed to provide clean, efficient, and reliable steam supply for brewery, distillery, washing, and commercial applications. It uses electric heating technology to generate steam quickly without combustion emissions.

This steam generator features high thermal efficiency, compact structure, and fully automatic operation. It is ideal for industries requiring stable, energy-efficient, and environmentally friendly steam generation.

Technical Specifications

Specification	Rated evaporation	Rated steam temperature	Rated pressure	Water capacity	Dimensions (mm)
6 KW	9 kg/h	170ºC	0.7Mpa	24L	460*580*1180
9 KW	15 kg/h	170ºC	0.7Mpa	24L	460*580*1180
12 KW	25 kg/h	170ºC	0.7Mpa	24L	460*580*1180
18 KW	30 kg/h	170ºC	0.7Mpa	24L	460*580*1180
24 KW	45 kg/h	170ºC	0.7Mpa	24L	500*710*1180
36 KW	60 kg/h	170ºC	0.7Mpa	29L	500*710*1180
48 KW	70 kg/h	170ºC	0.7Mpa	29L	920*570*1500
72 KW	100 kg/h	170ºC	0.7Mpa	29L	920*570*1500
108 KW	150 kg/h	170ºC	0.7Mpa	29L	920*570*1500
144 KW	200 kg/h	170ºC	0.7Mpa	29L	910*700*1780
162 KW	250 kg/h	170ºC	0.7Mpa	29L	950*650*1460
192 KW	300 kg/h	170ºC	0.7Mpa	29L	950*650*1460

Key Features

• High steam output：Provides 150 kg/h steam capacity suitable for commercial and industrial use.
• Electric heating system：Clean and environmentally friendly operation with no fuel combustion.
• Fast steam generation：Quick start-up improves production efficiency.
• Fully automatic operation：Automatic control system ensures safe and easy operation.
• Energy-saving design：High thermal efficiency reduces operating costs.
• Compact structure：Space-saving design allows easy installation.

Applications

• Brewery
• Distillery
• Commercial laundry
• Food processing
• Hospital sterilization
• Cleaning industry
• Commercial steam supply

FAQ

• Q1: What is the steam capacity?
  The steam capacity is 150 kg per hour.
• Q2: What is the power consumption?
  The rated power is 108 kW.
• Q3: Is it suitable for brewery use?
  Yes. It is widely used in breweries and distilleries.
• Q4: Is it fully automatic?
  Yes. It supports automatic operation.
• Q5: Do you provide technical support?
  Yes. Installation and technical support are available.

Why Choose Our Electric Steam Generator

• Clean and environmentally friendly
• High efficiency and energy saving
• Fully automatic operation
• Stable and reliable steam supply
• Compact and easy installation
• Customizable solutions available
