Gear reducer, Power Transmission
190RV E Series Cycloidal Gear Robot Arm Reducer Rrecision Reducer Cycloidal Pin Wheel Robot Manipulator Joint Reducer
- Outline dimension: φ222mm
- Allowable moment: 1600 N.m
- Torsional rigidity: 108 N.m/(Arc.min)
- Life: 6000h
- Weight: 9.3kg
NOTE: Prices may vary by product model and material.
$1,182.00
CompareSuch precision reducer is particularly applicable to robots, CNC equipment, aerospace equipment, defense equipment and weapons requirements of high-precision control of the transmission system.
| Model | 190BX |
| Outline dimension | Φ222mm |
| Reduction ratio | 81,105,121,153 |
| Allowable moment | 1600 N.m |
| Torsional rigidity | 108 N.m/(Arc.min) |
| Instantaneous maximum torque | 2000 N.m |
| Transmission accuracy | 1.0 Arc.min |
| Backlash of backlash | 1.0 Arc.min |
| Life | 6000h |
| Weight | 9.3kg |
