Name
|
|
Clamping range
|
14”-26”
|
Max tire diameter
|
1600mm / 63”
|
Max tire width
|
780mm / 31”
|
Max tire weight
|
500kg
|
Hydraulic motor power
|
1.5kw
|
Gear box motor power
|
1.5kw
|
Bead breaker force
|
2500kg
|
Power supply
|
110/220/380V, 50/60Hz
|
Net weight / Gross weight
|
740kg / 800kg
|
Packing dimension
|
2030*1590*940mm
|
Features:
2, Self-centering hydraulic clamping chuck.
3, Heavy tapered roller bearings, and a dual direction hydraulic motor provide smooth torque.
4, Quick positioning and locking mount/demount arm.
5, Hydraulic sliding carriage for positioning, bead loosening, mounting, and demounting procedures.
6, Single piece frame for superior rigidity.
7, Massive chuck spindle handles the heaviest loads.
8, Simple design is easy to use.
9, Very gentle on over-the-road tires and tubeless tires mounted on a aluminum wheels.
