Stretch Wrapping Machine Automatic Swing Arm Pallet Stretch Wrapper
Options：
* Infeed and Outlet Conveyor;
* Increased Wrapping Height;
* Enlarged Pallet Size;
* Power Supply Based on Country of Destination;
* Electrical Configurations;
* Safety Fence, Interlock and Light Curtain;
* Top Presser;
* Scale + Display / Scale + Display + Printer;
* Remote Control;
$10,380.00
CompareRotary Swing Arm Pallet Stretch Wrapper is Designed to Keep the Load Immobile and Wrap it with Stretch Film Using a Mechanical Rotating Arm. Stand-alone Using or Intergrated into Production Line, the Rotary Swing Arm Stretch Wrapper is Suited for Medium / High Production Capacity and for Unstable Loads.
Stretch Wrapping Machine Specification:
|
Packing Size Max. |
L 500 – 1200 mm × W 500 – 1200 mm |
| Wrapping Height Max. | 2000 mm |
| Efficiency | 45 – 50 loads/h |
|
Load Capacity |
2000 kg |
| Rotary Arm Rotation Speed | 0 – 12 rpm, variable |
| Protection System | Auto Sense Emergency Brake System |
|
Film Delivery System |
Powered Roller Pre-Stretch System Up to 300% |
| Automatic Film Clamper and Cutter |
Std. |
|
Middle Buffer Conveyor |
L = 3500 mm, Std. Powered Roller conveyor (Chain Conveyor / Slat Chain Conveyor optional) |
| Conveyor Speed |
12 m/min, constant |
|
Stretch Film |
LLDPE Stretch Film in 500 mm width × 15 – 35 um thickness; Film Reel in 76 mm core diameter × Max. 250 mm OD |
| Air Supply | 6 – 8 kg/cm2 |
| Voltage | 380 VAC 3 ph 50/60 Hz |
| Power | 3.5 kw |
| Machine Size | L 4200 mm × W 2000 mm × H 3700 mm |
| Machine Weight | 1000 kg |
