Precision Optical Profile Projector for Dimensional Measurement

The Image Measuring Machine is a high-precision lab-oriented measurement tool designed for accurate dimensional and geometric detection. Equipped with core high-performance components—including Taiwan HIWIN P-grade guide rails for stable movement and an American TEO color industrial HD CCD for clear image capture—it delivers reliable precision of XY (2.5 + L/200) μm, paired with a 0.0005mm grating scale resolution to ensure ultra-fine measurement results.

With a 400W power supply, 220V voltage compatibility, and practical structural specifications (300200200mm stroke, 460*360mm working table, 280kg weight, and 20kg loading capacity), it fits seamlessly into lab environments. Supporting OEM/ODM customization to meet specific lab needs and backed by a 1-year warranty, this machine excels in key lab applications: precision part dimensional testing, electronic component geometric verification, mold accessory precision inspection, lab sample 3D size measurement, and micro-component contour checking. It serves as a critical tool for enhancing lab measurement efficiency and ensuring data accuracy in precision manufacturing-related R&D and quality control processes.
