Technical Parameters of the Multihead Weigher 32-Head
Weighing heads | 32 |
Weighing range | 5-240g |
Weighing accuracy range | x (0.5) |
Maximum weighing speed | 60P/M |
Hopper capacity | 0.5L |
Operation interface | 10.4″ touch screen |
Optional equipment | Pattern scale hopper/collecting hopper/data printing device |
Drive mode | stepper motor |
Power requirements | 220V/2500w/50/60Hz/15A |
Package Size | 2100mm (L) ×1480mm (W) ×1130mm(H) |
Package weight | 600kg |
Features of the of the Multihead Weigher 32-Head
- High-speed asynchronous discharging function effectively prevents material blocking.
- Brand new highly integrated modular design, using CAN bus technology.
- An independent main vibrator is used to control the feeding thickness of materials respectively.
- The integrated chassis and middle base enhance the rigidity and strength of the machine, making weighing more accurate.
- Unified design standards and the use of mold manufacturing technology make each component more interchangeable.
- The weight of the mixture can be automatically compensated by the last material.
- The stable aluminum shell structure makes the hopper run more stable and the readings more accurate. The integrated chassis and middle seat enhance the strength of the machine and shorten the hopper’s stabilization time.
