Technical Parameters of the Mini Laminating Machine
Description | LM-3510 | LM-3810 | LM-4810 |
Laminating width | 330mm/12.99” | 380mm/14.96” | 480mm/18.89” |
Laminating thickness | 2-3mm | 2-3mm | 2-3mm |
Width for the film | 330mm/12.99” | 380mm/14.96” | 480mm/18.89” |
Diameter for paper core | 25.4mm/1” | 25.4mm/1” | 25.4mm/1” |
Temperature display | Digital Display | Digital Display | Digital Display |
Reverse function | Yes | Yes | Yes |
Speed adjustable | No. | No | No |
Power | 600W | 650W | 650W |
Rollers | 4 | 4 | 4 |
Diameter for the roller | 30mm | 30mm | 30mm |
MEANS(L×W×H) | 625×390×700mm | 670×335×650mm | 810×435×745mm |
N.W./G.W. | 20 kg/22 kg | 22kg/24kg | 26kg/30kg |
Product details
- Clutch adjustment
Adjust the left and right clutches, so that the gap between the upper and lower rubber roller is suitable for different thickness of paper. - Control panel
Showing the temperature, and adjust the working temperature.
- Insert paper width
The laminating width have 330mm, 380mm, 480mm, suitable for different sizes of paper. - lnsert paper backer
Adjust the paper backer to accommodate different sizes of paper. - Four rubber sticks
Four laminating film sticks, laminating fast and smooth.
- Metal working platform
Firm and durable, the machine runs more stably. - Rubber foot pad
Four rubber foot mats at the bottom of the body, stabilize the body and enhance heat dissipation for long-term operation.
- Temperature sensor
Monitoring the temperature change, more safer. - Power switch
From left to right are power sockets and power switches.
