Enclosed Tubular Chain Conveyor Product Introduction

The Enclosed Tubular Chain Conveyor is a fully sealed bulk material conveying system designed for powders, granules, pellets, and particles in food, chemical, pharmaceutical, and industrial applications. Using a continuous drag chain structure inside enclosed tubes, the system supports horizontal, inclined, and vertical conveying with low energy consumption and minimal material damage. Its dust-free design helps reduce contamination and improves workplace cleanliness during material transfer. The conveyor is suitable for handling flour, coffee powder, feed, chemicals, fertilizers, and abrasive materials. With flexible layouts, multiple inlet and outlet options, and stable continuous operation, this tubular chain conveyor provides an efficient and reliable solution for modern bulk material handling systems.

Working principle

Step 1: Material Feeding

Bulk materials enter the conveyor pipeline through the inlet hopper or feeding station.

Step 2: Chain and Disc Movement

The motor-driven chain moves continuously inside the enclosed tube with evenly spaced discs attached to the chain.

Step 3: Material Drag Conveying

The discs gently push and drag materials through the pipeline while maintaining stable flow and minimal product damage.

Step 4: Multi-Directional Transportation

Materials can move horizontally, vertically, or at inclined angles according to the production layout requirements.

Step 5: Material Discharge

Bulk materials are discharged smoothly through single or multiple outlet points for downstream processing or packaging.

Step 6: Continuous Closed-Loop Operation

The chain returns to the drive section for continuous conveying cycles with low dust emissions and stable performance.

Product Parameter Table

Parameter	Specification
Pipe Diameter	DN 273 mm
Capacity	16-48 m³/h
Wire Speed	0.2-0.35 m/s
Power	5.5-22 kW

Tubular Chain Conveyor vs Other Conveying Systems

Main Features

Dust-Free Enclosed Conveying Fully sealed pipeline structure prevents dust leakage and reduces environmental pollution during powder and particle conveying processes.

Flexible Multi-Directional Layout Supports horizontal, inclined, and vertical conveying combinations for complex factory layouts and limited installation spaces.

Gentle Material Handling Low-speed chain conveying minimizes material breakage, segregation, and product damage during transportation.

Wide Material Compatibility Suitable for powders, granules, pellets, flakes, sticky materials, abrasive products, and fragile bulk solids.

Low Energy Consumption Efficient drag chain conveying mechanism reduces power consumption compared with traditional pneumatic conveying systems.

Multiple Inlet and Outlet Design Supports multi-point feeding and discharge configurations for automated production line integration.

Stable Continuous Operation Heavy-duty chain structure ensures reliable conveying performance with high tensile strength and long service life.

Easy Cleaning and Maintenance Modular structure allows convenient inspection, maintenance, and cleaning for food-grade and industrial applications.

Corrosion and Wear Resistance Optional stainless steel construction improves durability in corrosive, humid, or sanitary production environments.

Space-Saving Conveyor Design Compact tubular conveying system reduces equipment footprint while maximizing conveying efficiency.

Why Choose Our Enclosed Tubular Chain Conveyor

1. Dust-Free Conveying
   Fully enclosed structure reduces dust leakage and material contamination.
2. Flexible Installation
   Supports horizontal, inclined, and vertical conveying layouts.
3. Gentle Material Handling
   Minimizes product breakage and material segregation during conveying.
4. Low Energy Consumption
   Consumes less power compared with pneumatic conveying systems.
5. Strong and Durable Structure
   Heavy-duty chain design ensures stable long-term operation.
6. Multiple Inlet and Outlet Options
   Supports customized feeding and discharge requirements.
7. Easy Maintenance
   Modular design simplifies cleaning, inspection, and maintenance.
8. Food-Grade Material Available
   Optional stainless steel construction for sanitary applications.
9. Wide Material Compatibility
   Suitable for powders, granules, pellets, and abrasive materials.
10. Custom Conveyor Solutions
    Customized size, capacity, and layout according to production needs.

Application Scenarios

• Food Industry
  Convey flour, milk powder, sugar, coffee powder, grains, spices, and feed materials safely and cleanly.
• Chemical Industry
  Suitable for chemical powder, additives, pigments, fertilizer, resin, and industrial bulk material handling.
• Pharmaceutical Industry
  Used for sanitary conveying of medicine powder, additives, and pharmaceutical raw materials.
• Agriculture Industry
  Efficient for grain transfer, seed conveying, and animal feed transportation applications.
• Mineral Industry
  Handles cement, fly ash, lime powder, silica sand, and abrasive mineral materials reliably.
• Recycling Industry
  Suitable for biomass conveying, waste powder handling, and industrial recycling systems.

Buying Guide

1. Confirm Material Type
   Check whether the material is powder, granule, pellet, sticky, or abrasive.
2. Choose Conveying Capacity
   Select suitable capacity based on hourly production requirements.
3. Determine Conveyor Layout
   Confirm horizontal distance, vertical height, and installation space.
4. Select Conveyor Material
   Choose carbon steel or stainless steel according to application needs.
5. Consider Dust Control Needs
   Enclosed systems are ideal for clean and dust-free production environments.
6. Confirm Feeding and Discharge Points
   Multiple inlets and outlets improve production flexibility.
7. Check Material Temperature
   High-temperature materials may require special conveyor components.
8. Consider Maintenance Access
   Choose designs with convenient inspection and cleaning access.
9. Match Industry Standards
   Food and pharmaceutical industries may require sanitary construction.
10. Choose an Experienced Manufacturer
    Professional technical support helps improve conveying efficiency and system reliability.

FAQ

Q1: What materials can a tubular chain conveyor handle?

A: Tubular chain conveyors can transport powders, granules, pellets, flakes, sticky materials, abrasive products, and fragile bulk solids across various industries.

Q2: Is an enclosed tubular chain conveyor suitable for food-grade applications?

A: Yes. Stainless steel food-grade tubular chain conveyors are widely used for flour, milk powder, coffee, sugar, spices, and grain conveying.

Q3: How does a tube chain conveyor reduce dust pollution?

A: The fully enclosed pipeline structure prevents dust leakage during conveying, transfer, and discharge operations.

Q4: Can a pipe chain conveyor move materials vertically?

A: Yes. The system supports horizontal, inclined, and vertical conveying configurations in one integrated conveyor line.

Q5: What is the advantage of a tubular drag chain conveyor over pneumatic conveying?

A: Tubular chain conveyors consume less energy, reduce product breakage, and minimize material segregation compared with pneumatic systems.

Q6: Can the conveyor handle abrasive or sticky materials?

A: Yes. Heavy-duty chain structures and wear-resistant components allow stable conveying of abrasive and sticky bulk materials.

Q7: Is multiple inlet and outlet design available?

A: Yes. Customized systems can include multiple feeding and discharge points for automated production processes.

Q8: What industries use enclosed tube chain conveyors most frequently?

A: Food processing, chemical manufacturing, pharmaceuticals, agriculture, minerals, recycling, and building material industries commonly use these systems.

Q9: How do I choose the right tubular conveyor capacity?

A: Capacity selection depends on material density, particle size, conveying distance, and hourly production requirements.

Q10: Does the enclosed conveyor system reduce product contamination?

A: Yes. The sealed pipeline design protects materials from external contamination and maintains product cleanliness during transport.

Conclusion

The Enclosed Tubular Chain Conveyor is an efficient, flexible, and dust-free bulk material handling solution for modern industrial conveying applications. With gentle product handling, low energy consumption, customizable layouts, and reliable continuous operation, this tube chain conveyor system is ideal for transporting powders, granules, pellets, and abrasive materials across food, chemical, pharmaceutical, agricultural, and mineral industries. Its enclosed design improves workplace cleanliness, protects product quality, and supports automated production line integration while reducing operational and maintenance costs.
