Food Vacuum Packing Machine Solution for Butter Cheese

Product introduction of Food Vacuum Packing Machine

Food Vacuum Packing Machine, also known as thermoforming packaging machine or roll stock vacuum packaging machine, is an advanced automatic horizontal packaging system widely used in food and non-food industries.

The machine forms packages using two film rolls—forming film (bottom) and sealing film (top). It supports vacuum packaging, MAP (modified atmosphere packaging), nitrogen filling, and vacuum skin packaging (VSP), making it suitable for a wide range of industrial applications.

It is commonly used in meat processing plants, cheese packaging factories, seafood production lines, medical device packaging, and chemical product packaging industries.

Working principle

Step 1: Bottom film (forming film) is fed into thermoforming station
Step 2: Film is heated and stretched into tray-shaped cavities
Step 3: Products are automatically or manually loaded into cavities
Step 4: Optional nitrogen or MAP gas is injected into packs
Step 5: Top sealing film is aligned over filled cavities
Step 6: Vacuum sealing chamber removes air from packaging
Step 7: Vertical sealing system applies heat and pressure sealing
Step 8: Cutting system separates finished packs into units
Step 9: Finished products are discharged automatically
Step 10: Fault monitoring system ensures continuous safe operation

Product Parameter Table

Parameter	Specification
Top Film Width	495-496 mm
Bottom Film Width	522-523 mm
Vacuum Degree	≤1000 Pa
Compressed Air Pressure	≥0.6 MPa
Air Inlet Specification	Φ16 PU pipe
Cooling Water Pressure	≥0.15 MPa
Power Supply	3 Phase, 380 V,50 Hz, Customizable
Total Rated Power	About 18 kW
Operating Speed	5-7 cycles/min
Machine Net Weight	About 2400 kg
Machine Overall Dimensions	About 8200×1050×1900 mm

Comparison Table

Main Features

• Thermoforming dual film packaging system (top and bottom film)
• Supports vacuum packaging, MAP, and vacuum skin packaging (VSP)
• 4-axis linear bearing lifting system ensures stable sealing movement
• German Igus linear bearings for smooth and precise operation
• Airtac pneumatic cylinders ensure vertical sealing pressure accuracy
• High-strength Al-Mg alloy frame for durable industrial structure
• 304 stainless steel support frame with precision milling processing
• Automatic alarm system with intelligent fault detection and display
• Fault memory reset function improves efficiency and reduces waste
• Dry and dehumidification electrical system for stable operation

Why Choose This Machine

Why choose thermoforming vacuum packaging machine instead of tray sealing machine?
Thermoforming machines create full production-line packaging, while tray sealers are limited to pre-formed trays.

Why choose Food Vacuum Packing Machine for industrial use?
It supports vacuum, MAP, and VSP, making it suitable for multiple industries and product types.

Why choose dual-film roll stock packaging system?
It reduces packaging cost and increases production efficiency with continuous operation.

Why choose intelligent alarm and fault memory system?
It improves uptime, reduces downtime, and prevents production waste.

Why choose aluminum alloy frame structure?
It ensures high durability, stability, and long-term industrial performance.

Application Scenarios

• Meat and poultry vacuum packaging production lines
• Cheese and dairy product industrial packaging systems
• Seafood and aquatic product preservation packaging
• Fresh vegetables and fruit MAP packaging solutions
• Sandwich and ready-to-eat food packaging industries
• Medical device sterile packaging applications
• Chemical and industrial product protective packaging

Buying Guide

Before purchasing a food vacuum packing machine, consider:

• Product type (meat, cheese, seafood, medical devices)
• Packaging method (vacuum, MAP, VSP requirements)
• Required production speed and automation level
• Film type compatibility (rigid or flexible packaging films)
• Factory space and production line integration
• Frame structure quality (aluminum alloy vs standard steel)
• Electrical control system stability and safety features
• After-sales service and spare parts availability

FAQ

Q1: What is food vacuum packing machine used for?
A1: It is used for thermoforming vacuum, MAP, and skin packaging of food and non-food products.

Q2: What is thermoforming packaging machine in food industry?
A2: It is a roll stock packaging system that forms packaging directly from film rolls.

Q3: Can this machine pack meat, cheese, and seafood?
A3: Yes, it is widely used for meat, cheese, sausage, and aquatic products packaging.

Q4: What packaging methods does this machine support?
A4: It supports vacuum packaging, MAP gas filling, and vacuum skin packaging (VSP).

Q5: How does dual film system improve packaging efficiency?
A5: It allows continuous forming and sealing, increasing production speed and reducing cost.

Q6: Is thermoforming vacuum packaging machine suitable for medical products?
A6: Yes, it is used for sterile medical device packaging and industrial safety packaging.

Q7: What makes this machine more stable than traditional vacuum packers?
A7: It uses aluminum alloy frame, linear bearings, and intelligent control systems.

Q8: Does the machine support fault detection and automatic stop?
A8: Yes, it has automatic alarm and intelligent fault memory reset functions.

Summary

Food Vacuum Packing Machine is a high-end thermoforming packaging solution designed for modern industrial production. It integrates vacuum sealing, MAP gas flushing, and vacuum skin packaging into one continuous system. With intelligent control, strong frame structure, and high-efficiency roll stock technology, it is widely used in meat, cheese, seafood, and medical packaging industries. It delivers stable performance, reduced packaging cost, and long shelf life protection, making it an ideal solution for large-scale food production lines.
