500L Automatic CIP System for Food Processing Cleaning
The 500L Food Grade CIP System provides efficient and reliable pipeline and tank sanitation for food and beverage production. Using automated circulation cleaning with high-temperature cleaning liquids, pumps, and pneumatic valves, it thoroughly removes residues, bacteria, and contaminants without the need for equipment disassembly. The system supports programmable cleaning cycles and stable temperature control, ensuring consistent hygienic standards. It is widely used for cleaning tanks, pipelines, and processing equipment in dairy, juice, beverage, and brewery production lines.
$9.00
Compare500L Automatic CIP System Product Introduction
The 500L Food Grade CIP System is designed for hygienic cleaning of pipelines, tanks, and processing equipment in food and beverage factories. The system performs automatic in-place cleaning by circulating high-temperature cleaning liquids through pipelines and equipment surfaces without disassembly. Controlled by a PLC system, pumps, and pneumatic valves, it automatically prepares cleaning solutions and completes the full cleaning cycle including circulation, draining, and recovery. Adjustable parameters such as cleaning time, temperature, and chemical concentration ensure stable and effective sanitation results. Its compact structure, reliable operation, and high automation level help reduce labor, prevent secondary contamination, and improve production efficiency. It is widely used in dairy, juice, beverage, and brewery production environments requiring strict hygiene standards.
Technical Specifications：
| Processing | Washer |
| Core Components | PLC, Motor, Pump |
| Voltage | 220V / 380V / 400V (Customizable) |
| Power (W) | 2.2–18 kW |
| Dimension (L×W×H) | 3000 × 1400 × 2000 mm |
| Capacity | 500 L (Range: 500L – 30,000L) |
| CIP Tank Type | Alkali Tank, Acid Tank, Hot Water Tank, Clean Water Tank, Water Recycle Tank |
| Cleaning Circuits | Single, Double, Triple, Quadruple (Customizable) |
| Heating Method | Internal Coil, Plate Heat Exchanger, Tubular Heat Exchanger |
| Automatic Types | Full Automatic / Semi-Automatic / Manual |
| Full Automatic Features | Flow Rate Auto Control, Temperature Auto Control, Auto Liquid Level Compensation, Auto Concentration Compensation, Cleaning Liquids Auto Transfer, Auto Alarm |
| Processing Types | 5–100 Gallon Water Bottles, Food Processing Equipment |
| Material | SUS304 & 316L Stainless Steel |
| Cleaning Method | Clean-In-Place (CIP) |
| Automatic Grade | Semi-Automatic & Full Automatic |
| Application | Beverage, Milk, Wine, Chemical, Food Processing |
| Structure Type | One-piece and Split |
Main features：
- Food Grade Stainless Steel Construction
Built with sanitary stainless steel to ensure corrosion resistance, durability, and compliance with food processing hygiene standards. - Efficient Circulation Cleaning System
Uses high-temperature cleaning liquid circulation to remove residues, bacteria, and contaminants from tanks and pipelines. - Automatic Cleaning Control
Equipped with an automated control system to manage cleaning cycles, temperature, and liquid circulation efficiently. - Compact and Integrated Design
Skid-mounted structure saves installation space and simplifies operation and maintenance. - Reliable and Hygienic Operation
Designed to reduce manual cleaning, prevent secondary contamination, and improve production efficiency.
Application Scenarios：
- Dairy Processing Plants
Suitable for cleaning milk tanks, pipelines, and processing equipment in dairy production lines. - Juice and Beverage Production
Ensures sanitary cleaning of pipelines and tanks used in juice and beverage manufacturing. - Brewery and Fermentation Systems
Used for cleaning fermentation tanks, pipelines, and related brewing equipment. - Food Processing Factories
Maintains hygienic conditions for tanks, mixers, and pipelines in various food processing environments. - Liquid Processing Production Lines
Ideal for automated cleaning of liquid handling systems requiring strict sanitary standards.
FAQ for 500L Automatic CIP System for Food Processing Cleaning
Q1: What is the core function of this 500L CIP system?
It is designed for automatic cleaning-in-place of tanks, pipelines, and other food processing equipment, eliminating the need for manual disassembly and ensuring hygiene standards.
Q2: What materials is this CIP system made of?
The main body and all parts in contact with the cleaning liquid are made of SUS304 / 316L stainless steel, which is food-grade, corrosion-resistant, and easy to clean.
Q3: Is this system fully automatic or semi-automatic?
It supports both semi-automatic and full-automatic operation. The full-automatic mode can control flow rate, temperature, liquid level, and concentration automatically, while the semi-automatic mode allows manual intervention for specific steps.
Q4: What industries is this 500L CIP system suitable for?
It is ideal for food processing, beverage, dairy, wine, and chemical industries, especially for cleaning production lines and equipment in medium-scale factories.
Q5: Can the cleaning process be customized?
Yes. You can set different cleaning cycles, acid/alkali soaking times, and flushing frequencies according to the specific residue characteristics of different food products.
Q6: What are the key advantages of this system?
It features easy operation, semi-automatic control, high cleaning efficiency, and compliance with food safety standards, effectively reducing labor costs and secondary pollution risks.
