3–12 m³/h Z Type Bucket Elevator Granular Hopper Conveyor

Z Type Bucket Elevator Product Introduction

The Z type bucket elevator is a versatile conveying equipment that elevates materials from low to high positions with high efficiency, making it essential for industries such as cement, coal, gypsum, limestone, dry clay, food, and chemical processing. With a horizontal length of 1.2–40 meters and vertical lift up to 100 meters, it handles materials gently without causing damage, reducing scrap and waste. The hopper is available in high-strength plastic, carbon steel, or stainless steel, offering corrosion resistance, high temperature tolerance, and durability. It suits manufacturers needing reliable, fully enclosed, hygienic bulk material transportation with system linkage capabilities.

Working Principle

Materials enter the hopper at the bottom and are captured by the buckets on a moving belt. The belt lifts the material vertically, then discharges it at the desired horizontal or inclined exit. The elevator can operate with single or multiple feeding/discharge points and is compatible with vibration feeders for integrated system operation.

Product Parameter Table

Machine frame	Good quality 304 stainless steel or carbon steel
Bucket material	Food grade ABS or PP plastic or 304 stainless steel
Bucket size	1.8 L or 4 L or 6 L
Speed	Controlled by Delta inverter, adjustable
Max speed	90 buckets/min
Working capacity	3-12 m³/h
Lifting height	1.5 m standard height or Custimized
Chains	Good quality 304 stainless steel or carbon steel
Outlets	1/2/3 or others
Voltage	110 V/220 V single phase or 380 V 3phase, 50 Hz/60 Hz
Power	750 W

Main Features

• Horizontal and vertical transmission allows flexible installation and smooth material handling over long distances.
• High-strength plastic hopper provides corrosion resistance, heat tolerance, and deformation-free operation under heavy loads.
• Multi-point automatic feeding and unloading supports connection with multiple silos for efficient production.
• Fully enclosed design ensures hygienic operation while minimizing dust and contamination during material handling.
• Integration with vibration feeders improves system linkage and overall material lifting rate for higher productivity.

Application Scenarios

• Elevating bulk materials such as cement, gypsum, coal, and limestone in construction industries.
• Transporting granular and powdered food ingredients, frozen products, or snack items in food processing plants.
• Lifting chemicals, fertilizers, and powdered raw materials in chemical and agricultural industries.
• Connecting multiple silos or feeding points in automated production lines.
• Suitable for hygienic applications with fully enclosed design for dust-free operations.

FAQ

Q1: What materials can the Z type bucket elevator handle?

A1: It is suitable for bulk solids and granular materials, including cement, chemicals, food, frozen products, and powders.

Q2: Can it be used in food-grade applications?

A2: Yes, stainless steel and fully enclosed designs ensure hygienic operation.

Q3: What are the hopper material options?

A3: High-strength plastic, carbon steel, or stainless steel hoppers are available for different requirements.

Q4: Can it handle multiple discharge points?

A4: Yes, it supports single or multi-point feeding and discharge with sensors for automatic control.

Contact us to get your quotation now.

Get in touch with our engineering team.

Download full specification PDF.
