Arc Welding Equipment & Accessories
200 Amp Digital Display 2 in 1 Electric Welding Machine MMA Welder
$99.00
CompareTechnical specifications of the Electric Welding Machine
| Model | ARC-200C(Z2H903) |
| Input power source | AC230V/1P±15% 50/60HZ |
| Rated input current(A) | 40 |
| Rated input power capacity(KVA) | 9.4 |
| Output current range (A) | 20～200 |
| O.C.V(V) | 81 |
| Duty cycle(%) | 60 |
| Efficiency(%) | 85 |
| Power factor(cosΦ) | 0.7 |
| Protection Class | IP21S |
| Insulation Class | H |
| Dimension(L×W×H) | 390mm×135mm×225mm |
| Net Weight(kg) | 4.5 |
| Applicable electrode(mm) | 1.6-5.0 |
Product Details
Related products
-
Arc Welding Equipment & Accessories
MMA Welding Equipment Welding Machine Portable MMA ARC IGBT Welders
Arc Welding Equipment & AccessoriesMMA Welding Equipment Welding Machine Portable MMA ARC IGBT Welders
Quick joint Size(mm):35-50mm
N.W./G.W.(kg):4/4.8
Machine Size(LxWxH mm):340*155*235
Package Dimension(LxWxH mm):395*195*320
honeycomb:box
Accessories:
1.8m 16mm 200A holder
1.2m 16mm 300A clamp
mask, brush, manualSKU: n/a
