2-4 Lanes Multi Column Packing Machine for Coffee Powder Use

Product introduction of Multi Column Packing Machine

The multi column packing machine is a fully automatic multi-lane packaging system designed for continuous sachet production from laminated roll films. It integrates feeding, volumetric or auger dosing, forming, sealing, cutting, printing, and conveying into one synchronized process. Built with full 304 stainless steel construction and PLC touch screen control, it ensures hygienic operation and stable performance. The machine supports various materials such as PET, aluminum foil, and nylon films. It is widely used in food, cosmetic, and chemical industries for packaging sauces, gels, liquids, powders, and semi-liquid products with high precision and efficiency.

Working Principle

The machine feeds roll film into multiple forming columns where sachets are shaped continuously. Each lane performs independent servo-controlled dosing according to preset parameters. Products are filled into formed sachets, followed by horizontal and vertical heat sealing using PID temperature control. The system then prints batch codes, cuts sachets, and conveys finished products automatically. Safety interlocks monitor doors and film supply, stopping operation when abnormal conditions occur. The PLC system synchronizes all processes to ensure stable, high-speed, and accurate multi column packaging operation.

Product Parameter Table

Lane Number	2-4 Lanes
Packing Speed	Max 50 bags / lane / min
Max Roll Film Width	280 mm
Bag Length	50-180 mm
Bag Width	25-70 mm
Power	3.5 kW
Dimension (L×W×H)	1385×918×2005 mm
Weight	300 kg

Main Features

• Independent servo auger dosing system for each lane ensures accurate and adjustable filling range control via PLC system.
• Motorized roller film dividing device eliminates waste film edge and improves material utilization efficiency during operation.
• Safety interlock system automatically stops machine when doors are opened or packaging film supply is interrupted.
• Double-layer heating barrel design with automatic stirring ensures uniform temperature distribution for viscous liquid materials.
• Heavy-duty machine structure supports long-term high-speed operation with reduced vibration and improved stability performance.
• Intelligent PID temperature control system maintains consistent sealing quality for different laminated film materials.

Application Scenarios

• Food industry packaging for ketchup, soy sauce, honey, jam, juice, and edible oil products
• Cosmetic industry applications including shampoo, facial cleanser, gel, and lotion sachets
• Chemical industry packaging for detergents, disinfectants, and industrial gel products
• Pharmaceutical and health care products such as medicinal syrup and nutritional liquids
• Multi-material laminated film packaging for diverse liquid, paste, and semi-solid products

FAQ

Q1: What materials can this machine handle?
It supports liquids, pastes, gels, powders, and semi-liquid products.

Q2: What is the lane capacity?
The machine supports 2–4 lanes with up to 50 bags per lane per minute.

Q3: Does it support different film types?
Yes, it supports PET, aluminum foil, nylon, and laminated films.

Q4: Is the filling system adjustable?
Yes, servo dosing and PLC control allow automatic adjustment.

Q5: Does it include safety protection?
Yes, it has door interlock and film detection stop systems.
