2-100ML Hot Sauce Filling Machine，Packaging Machines
| Pouch length | 50-300mm (adjustable) |
| Pouch width | 35-105mm |
| Packing speed | 30-60 times/min |
| Filling capacity | 2-100ml |
| Applicable film | PET/ALIPE PET/PE NY/AL/PE NY/PE |
| Max film width | 900mm |
| Max film diameter | Φ 300mm |
| Film core diameter | Φ 75mm |
| Electric source | 380V 50HZ (do as customer’s request) |
| Total power | 12KW |
| Overall dimension | 2200x1900x2600mm(LxWXH) |
| Machine weight | 1500Kg |
$45,800.00 $50,000.00
Hot Sauce Filling Machine automatically packs materials into small bags according to metering requirements, such as peanut oil, salad oil, ketchup, and cough syrup.
Features
Structure and performance: high strength, low noise, compact structure, smooth operation, easy maintenance, long service life.
Drive and control: five-axis servo synchronous drive, human-machine interface touch adjustment, PLC control, to achieve precise positioning.
Automation: can complete multiple operations at one time, including sealing, cutting, filling, coding, finished bag output, etc.
Sealing and speed: using high-precision heat sealing rollers, four-side sealing, multi-row bag shape, to ensure tight sealing, fast packaging speed, beautiful bag shape.
Convenient adjustment: no need to change the mold, you can adjust each function through the human-machine interface.
Accurate measurement: design a metering system specifically for different slurry materials to ensure accurate filling.
Control system: the whole machine is PLC controlled, the actuator is driven by a servo motor, and the automatic positioning is reliable.
Photoelectric tracking: ensure the double-sided pattern alignment of the packaging bag, and has an automatic counting function.
Strong material adaptability: with high-precision temperature control function, suitable for a variety of packaging films.
Additional functions: can add dotted line knives, flat cutters, special-shaped knives and different coding and alarm functions.
Main Technical Parameters
| Model | Hot Sauce |
| Pouch length | 50-300mm (adjustable) |
| Pouch width | 35-105mm |
| Packing speed | 30-60 times/min |
| Filling capacity | 2-100ml |
| Applicable film | PET/ALIPE PET/PE NY/AL/PE NY/PE |
| Max film width | 900mm |
| Max film diameter | Φ 300mm |
| Film core diameter | Φ 75mm |
| Electric source | 380V 50HZ (do as customer’s request) |
| Total power | 12KW |
| Overall dimension | 2200x1900x2600mm(LxWXH) |
| Machine weight | 1500Kg |
