1T/H RO Water Treatment System for Industrial Drinking Water

Product Introduction 1T/H RO Water Treatment System

 The 1T/H reverse osmosis RO water treatment system is a reliable and efficient solution designed for industrial and commercial water purification applications. With a processing capacity of 1 ton per hour, the system is constructed using high-quality materials to ensure durability, stable performance, and long service life in continuous operation environments.

This equipment is engineered to remove dissolved solids, organic contaminants, bacteria, and suspended particles from various raw water sources such as groundwater, tap water, and surface water. By combining pre-treatment filtration with advanced reverse osmosis membrane separation, the system provides consistent and high-quality purified water suitable for a wide range of uses.

It is widely applied in industries such as food and beverage processing, pharmaceutical production, and general manufacturing, as well as in commercial water supply systems. The system is ideal for users who require dependable water purification with moderate capacity and efficient operation.

Technical Specifications

Item	Parameter
Product Name	Water Treatment System for Reverse Osmosis Plants
Production Capacity	1 t/h
Treatment Type	Reverse Osmosis, Softening, Desalination, Filtration, Ion Exchange
Power	2.2 kW
Voltage	220V, 380V, 110V
Usage	Liquid Filter
Dimensions	1680×680×1680 mm
Filtration Process	Quartz Sand + Activated Carbon + Resin Softening + Precision Filter + RO + UV
Application	Wastewater Treatment Plants
Weight	150 kg

Main features

• 1T/H processing capacity suitable for continuous industrial and commercial water purification applications
• Advanced reverse osmosis membrane effectively removes up to 99% of dissolved solids and contaminants
• Multi-stage filtration system improves water quality and extends the service life of membranes
• Stable high-pressure pump ensures consistent water flow and reliable long-term operation
• Durable construction with corrosion-resistant materials suitable for various working environments
• User-friendly control system enables easy operation, monitoring, and maintenance

Working principle

The system uses a multi-stage purification process. Raw water first flows through pre-treatment units including sand filters and activated carbon filters to remove suspended solids, chlorine, and organic substances.
The pre-treated water is then pressurized by a high-pressure pump and passed through the reverse osmosis membrane. The semi-permeable membrane allows water molecules to pass while rejecting dissolved salts, bacteria, and impurities.
Purified water is collected for use, while concentrated wastewater containing rejected contaminants is discharged, ensuring effective separation and stable operation.

Application scenarios

• Drinking water purification for factories, schools, and commercial facilities
• Groundwater and tap water treatment for safe and clean water supply
• Food and beverage production requiring purified process water
• Pharmaceutical and laboratory water purification systems
• Small to medium-scale water treatment plants
• Pre-treatment for advanced filtration and desalination systems

FAQ

Why Choose Us

• Mature reverse osmosis technology ensuring stable and efficient water purification performance
• High-quality components selected for durability and long service life
• Energy-efficient system design helps reduce operational costs and improve efficiency
• Strict quality control ensures consistent performance and reliable operation
• Wide range of applications suitable for different industries and water sources
• Professional technical support for installation and operation guidance

Contact us to get your quotation now.

Get in touch with our engineering team.
