Semi Automatic Double Wire Metal Coil Spiral Book Binding Machine Spiral Binding Machine
Working speed up to 1200~1700 books per hour
Binding diameters can be 1/4″- 7/8″, pitch can be 3:1 or 2:1
Skp-binding at one time are available,up to 5 skips binding per once
Touch screen and automatic error reminder
Automatic hanger binding device ,automatic books convey device
New slide-type pneumatic components extend the machine life and ensure the machine stability
$6,717.00
Compare|
Feeding Mode
|
manual delivery
|
|
Wire spec
|
auto cut,bind
|
|
Max.Paper Width
|
520 mm
|
|
Max.Binding Width
|
507mm
|
|
Min.Paper length
|
75mm
|
|
Working Speed
|
1200-1700T/hour
|
|
Size of Worktable
|
600*300mm
|
|
Power
|
220v/1ph/50hz
|
|
Air Compressor(not include)
|
1.5 KW
|
|
Air Pressure
|
6-8 ba
|
|
Main Machine Dimensions
|
1000*760*1230 mm
|
|
Net Weight
|
271 KG
|
|
Dimensions of pay-off unit
|
490*760*1230mm
|
|
Net weight of pay-off unit
|
54 KG
|
