Dimension
|
79*110*45mm
|
|
Print method
|
Thermal line printing
|
|
Paper width
|
57mm +/- 0.5mm
|
|
Print width
|
48mm
|
|
Weight
|
235 (not including the paper roll)
|
|
Max diameter of roll
|
40mm
|
|
Dot per lie
|
384 dots/line
|
|
internal characters
|
ASCII CH(8×16,9×17,9×24,12×24); GB18030(16×16,24×24)
|
|
Print speed
|
50~80mm/s
|
|
Life cycle time
|
50km(printing density under 12.5%)/100 million pulses
|
|
text and graphic Support
|
English, figure, symbol, Chinese, graph, curve, icon pre-stored, barcode(CODE39EAN13EAN8 CODABARCODE128CODE93ITF)
|
|
QR code ,PDF417
|
|
|
Dot pitch (resolution)
|
203DPI/8 dots/mm
|
|
interface
|
blue-tooth,Mini USB
|
|
Power
|
2000mAh 7.4V rechargeable Lithium battery
|
|
Recharge adapter
|
Stand by recharging / AC adapter
|
|
Self-check
|
Without paper / cover open
|
|
Black mark test
|
Supported
|
|
Paper feeding
|
Easy paper loading
|
|
commands
|
ESC/POS compatible with order sets
|
|
Paper cut
|
By hands
|
|
operate setting
|
Temperature -10°C~50°C ; Humidity 20%~85%
|
|
Recharge Setting
|
Temperature 5°C~40°C; Humidity 20%~85%
|
|
Storage Setting
|
Temperature -20°C~70°C ; Humidity 5%~95%
|
|
Standard accessories
|
Long-term preservable paper,AC adapter,li-ion battery,USB cable
|
|
Optional accessories
|
Serial interface cable/leather coat/CD
|
