Jinlang S6-EH1P(3-6)K-L-PRO independent power supply energy storage inverter, residential photovoltaic energy storage system, high-power photovoltaic off-grid inverter
S6-EH1P(3-6)K-L-PRO Kinlong independent power supply energy storage inverter is suitable for residential photovoltaic energy storage systems, and supports multiple parallel units to form a single-phase or three-phase system with a maximum power of 36kW. It has UPS switching level to ensure the safety and reliability of power consumption; the product supports 135A charge and discharge capacity, provides higher energy transmission density, and can realize 2 times the surge power capacity within 10 seconds, and has a variety of intelligent protection functions to make home power supply safe and reliable.
$2,725.00
CompareJinlang Independent Power Supply Energy Storage Inverter
Leading Features
UPS level and off-grid switching
Maximum charge and discharge current of 135A
6-segment timing charging and discharging function
2 times output for 10 seconds off-grid load capacity
A variety of ways to connect to the generator, which can control the generator to start and stop automatically
Support single-phase or three-phase network parallel connection, the maximum can build 36kW system
Support lithium battery and lead-acid battery, integrated battery treatment and protection function
Support “Peak Shaving” function in self-use and generator mode
| Specification | 530w, 535w, 545w |
|---|
