Jinlang Hybrid Inverter S6-EH3P(5-10)K-H-EU Series High Voltage Inverter Home Storage System New Version Energy Storage Inverter

Add to wishlist
Compare

S6-EH3P(5-10)K-H-EU series three-phase energy storage inverter is suitable for large residential and small industrial and commercial photovoltaic energy storage systems. This series of products has 3/4-way MPPT, which is the first choice for large-scale rooftop photovoltaic energy storage systems with more roof orientations and complex and diverse structures. The product has a variety of flexible load capacities, and can supply energy for loads more friendly and reliable.

$2,519.00

Compare

Jinlang three-phase high voltage energy storage inverter
Leading Features

Maximum 50A/10kW charge and discharge capacity
UPS level and off-grid switching
Support “Peak Shaving” mode
Multi-channel MPPT design, can be used for roofs with different orientations
Prefabricated battery and meter communication cables save installation time
Support the three-phase unbalanced output and half-wave carrier of the off-grid port
Compatible with various brands of battery models, providing customers with more battery options
Integrated battery therapy and protection functions to extend battery life

Specification
item
value
Place of Origin
China
Brand Name
Ginlong
Model Number
S6-EH3P(5-10)K-H
Input Voltage
1000V
Output Voltage
3/N/PE, 380 V / 400 V
Output Current
7.6A
Output Frequency
50Hz / 60Hz
Output Type
Three Phase
Size
600*500*230 mm
Type
DC/AC Inverters
Inverter Efficiency
%97.87
Certificate
G98 or G99, VDE-AR-N 4105 / VDE V 0124, EN 50549-1, VDE 0126 / UTE C 15/VFR:2019, RD 1699/RD 244 / UNE 206006 / UNE 206007-1, CEI 0-21, C10/11, NRS 097-2-1, TOR, EIFS 2018.2, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN 50530, MEA, PEA
Warranty
5 years
Weight
32.6
Battery Voltage
120V-600V
Inverter type
Hybrid Grid Inverter
Application
Solar Energy Storage System
Rated power
5 kW
Communication
CAN, RS485, Ethernet, Optional: Wi-Fi, Cellular, LAN
Battery type
Lithium Battery



Category: Tags: ,
Specification

530w, 535w, 545w
