JA n-type Bifacial Solar Panel JAM54D41 400W-425W/GB Series Double Glass Half-cell Black Module with 25 Years Warranty for Sale
Introduction
Powered by the latest SMBB n-type solar cell and half-cell configuration, these modules have higher output power, lower LID, better weak illumination response, and better temperature coefficient.
- Higher power generation better LCOE.
- Better weak illumination response.
- n-type with very Lower LID.
- Better Temperature Coefficient
$188.00 – $198.00
CompareModel of JA n-type Bifacial Solar Panel: 400W 405W 410W 415W 420W 425W
- >90% Higher Transmittance EVA, Higher GEL Content To Provide Good Encapsulation And Protect Cells From Vibration With Longer Durability.
- 21kV High-Voltage Breakdown Test, Better Durability Withstand Fire/Dust/UV/Tear Tests For Super Isolation Back Sheet, Multi-layer Structure.
- 12% Ultra Clear Tempered Glass.
- 30% Lower Reflection.
- 22% Higher Efficiency,5BB Cells.
- 93 Fingers PV Cells, Anti-Pid.
- 120N Tensile Strength Frame. 110% Seal-lip Design Glue Injection. (Black/Silver Optional)
- IP67 Waterproofness Junction Box.
- Innovative Full-Glue-Filled.
- 4mm2 Qualified cable with MC4.
- 500N Tensile Strength.
- Waterproof Labels.
| Cell | Mono-16BB |
| Weight | 21.5kg |
| Dimensions | 1722±2mm×1134±2mm×30±1mm |
| Cable Cross Section Size | 4mm²(IEC),12 AWG(UL) |
| No.of cells | 108(6×18) |
| Junction Box | IP68,3 diodes |
| Connector | MC4-EVO2A/ QC4.10-351 |
| Cable Length (Including Connector) | Portrait: 200mm(+)300mm(-); 800mm(+)800mm(-)(Leapfrog); Landscape: 1100mm(+)/1100mm(-) |
| Front Glass/Back Glass | 1.6mm/1.6mm |
| Packaging Configuration | 36pcs/Pallet, 936pcs/40HQ Container |
| Max. Power | 400W, 405W, 410W, 415W, 420W, 425W |
|---|
