pH Meter General Features:
1:High resolution LCD display screen, 6.0 inches.
2:Multi-reading feature allows auto-read and continuous-read.
3:Automatic/Manual temperature compensation ensures accurate results.
4:Auto-hold feature senses and locks the measurement endpoint.
5:Data Storage 50 sets for each parameter.
6:Reset feature automatically resumes all settings back to factory default options.
7:IP54 waterproof.
8:1-3 points calibration with Standard Recognition.
9:Automatic/Manual temperature compensation ensures accurate results
Parameters
|
pH/Temp.(mV)
|
|
pH
|
Range
|
-2.00 to 18.00 pH
|
Resolution
|
0.01 pH
|
|
Accuracy
|
±0.01 pH
|
|
Calibration Points
|
Up to 3
|
|
Standard Recognition
|
NIST buffers
|
|
mV
|
Range
|
-1999 to 1999 mV
|
Resolution
|
1 mV
|
|
Accuracy
|
±0.1%FS
|
|
Temperature
|
Range
|
-5 to 110 ºC(23 to 230 ºF)
|
Unit
|
ºC
|
|
Resolution
|
0.1
|
|
Accuracy
|
±0.2
|
|
Measurement
|
Reading Mode
|
Auto Read, Continuous
|
Reading Prompts
|
Reading, Stable, Locked
|
|
Temp. Compensation
|
ATC, MTC
|
|
Data management
|
Data Storage
|
50 results each
|
Inputs
|
pH Electrode
|
BNC(Q9)
|
Temp. Probe
|
4-pin aviation connector
|
|
Display options
|
Backlight
|
Yes
|
Auto Shutdown
|
300, 600, 1200, 1800, 3600 sec., off
|
|
IP Rating
|
IP54
|
|
General
|
Power
|
AC Adapter, 100-240V AC input, DC9V output
|
Dimensions
|
242×195×68 mm
|
|
Weight
|
900g (1.98 lb)
|
