Specification parameters of the Diesel Generator
Engine model | WP2.3D40E200 | Prime Power | 36 KW |
Engine manufacturer | Weichai | Standby Power | 40 KW |
Number of Cylinders | 4 Cylinders in line | Steady speed droop | ≤1% |
Cycle | 4 Stroke | Voltage | 400V |
Aspiration | Natural | Lube Capacity | 8 L |
Bore×Stroke | 82mm x 92mm | Fuel Consumption | 12.02 L/h |
Displacement | 2.289 L | Starter Motor | DC24V, |
Coolant Capacity for engine | 5 L | Alternator | DC24V |
Optional of the Diesel Generator
- Four protection systems: connected with the engine block, including water high temperature protection, low oil pressure protection, overcurrent protection, overload protection
- Mobile power station: also known as power generation vehicle/power supply vehicle, etc. Combine diesel engine/fuel tank/control panel/battery/generator/rainproof box into one.
- Fully automatic system: ATS system transfer switch provides monitoring, generator start-up and load transfer in emergency/alternative power supply occasions.
- Silent sound box: The soundproof sound box is a closed space designed to reduce the impact of unit noise on the outside world and block the way of noise transmission.
