Automatic Polymer Dosing Solution for Sludge Wastewater
The automatic polymer dosing system is an intelligent continuous powder preparation and dosing solution designed for wastewater and sludge treatment applications. It integrates dry powder feeding, wetting, mixing, curing, and automatic control in a single system. With PLC control and screw feeder dosing technology, it ensures precise polymer concentration, stable operation, and high mixing efficiency. The system is widely used in industrial wastewater treatment plants requiring accurate and continuous flocculant preparation.
Compare
Product introduction of Automatic Polymer Dosing Solution
The automatic polymer dosing system is an advanced continuous chemical preparation and dosing solution designed for industrial wastewater and sludge treatment applications.
It automatically converts dry polymer powder into a fully matured flocculant solution through controlled wetting, mixing, curing, and intelligent PLC-based dosing.
The system ensures stable flocculation performance, improves sludge dewatering efficiency, reduces chemical waste, and supports 24/7 industrial wastewater treatment operations.
What Is an Automatic Polymer Dosing System?
An automatic polymer dosing system is a fully automated equipment used to:
- Prepare polymer solution from dry powder
- Control polymer concentration precisely
- Deliver flocculant continuously to wastewater systems
It is widely used in sludge dewatering, solid-liquid separation, and industrial wastewater treatment plants.
Working principle
1. Dry Powder Feeding
Polymer powder is delivered from hopper via screw feeder.
2. Premixing & Wetting
Powder is mixed with clean water for initial hydration.
3. Dissolution & Mixing
Multi-stage mixing tank ensures full polymer activation.
4. Curing (Maturation) Process
Solution is stored in curing tank for complete reaction.
5. Automatic Dosing Output
Mature polymer solution is delivered to downstream system.
Product Parameter Table
| Capacity | 4000 L/h |
| External Dimension (L×W×H) | 4600×1900×2000 mm |
| Total Power | 4.77 kW |
| Main Tank Size (L×W×H) | 4500×1500×1000 mm |
| Material | SS304 / PP |
| Control System | PLC automatic control |
| Dosing Accuracy | ±1% |
Automatic Dosing System vs Manual Preparation
| Feature | Automatic System | Manual System |
|---|---|---|
| Accuracy | High (±1%) | Low |
| Labor Requirement | Low | High |
| Stability | High | Unstable |
| Continuous Operation | Yes | No |
Automatic System vs Batch Mixing System
| Feature | Continuous System | Batch System |
|---|---|---|
| Efficiency | High | Medium |
| Operation Mode | Continuous | Intermittent |
| Chemical Utilization | Optimized | Wasteful |
| Industrial Use | Ideal | Limited |
Conclusion: Continuous automatic dosing systems provide superior efficiency and stability for industrial wastewater treatment.
Main Features
1. High Automation with PLC Control
Real-time monitoring and automatic operation via HMI interface.
2. High Precision Screw Dosing System
Closed-loop control ensures feeding accuracy within ±1%.
3. Continuous Powder Preparation Process
Supports uninterrupted polymer solution production.
4. Three-Tank Integrated Design
Compact structure with mixing, curing, and storage tanks.
5. SS304 / PP Corrosion Resistant Construction
Ensures long service life in chemical environments.
6. Stable Mixing and Hydration Performance
Multi-stage blade mixer ensures complete dissolution.
7. Adjustable Concentration Control
Flow rate and screw speed adjust dosing concentration.
Application Scenarios
Municipal Wastewater Treatment
For unstable flocculation performance → ensures consistent polymer dosing → improves sludge settling efficiency
Industrial Sludge Dewatering
For poor solid-liquid separation → enhances floc formation → improves dewatering performance
Paper & Pulp Industry
For high suspended solids → stabilizes chemical dosing → improves process clarity
Textile Wastewater Treatment
For variable effluent quality → ensures consistent treatment → improves discharge compliance
Chemical Industry Wastewater
For complex organic load → improves coagulation efficiency → stabilizes process performance
How to Calculate Polymer Dosing Rate
Polymer dosage depends on:
- Sludge concentration (g/L)
- Flow rate (m³/h)
- Flocculation efficiency target
Basic Formula:
Polymer dosage = Flow rate × Concentration × Dosing ratio
Typical industrial range:
- 0.1–0.5% polymer solution concentration
- 1–5 kg polymer per ton of dry solids
Why Choose This System
This automatic polymer dosing system provides a stable, precise, and cost-effective solution for modern wastewater treatment plants.
Key advantages:
- Reduces chemical waste and operating cost
- Improves flocculation efficiency and sludge separation
- Ensures continuous and stable operation
- Minimizes manual intervention and labor cost
- Enhances overall wastewater treatment performance
FAQ
1. What is an automatic polymer dosing system used for?
It is used to prepare and dose flocculant solution for wastewater and sludge treatment.
2. How does polymer dosing system work?
It dissolves dry powder into water through mixing, curing, and automatic dosing process.
3. What is screw dosing system in polymer preparation?
It controls precise feeding of dry powder into the mixing chamber.
4. Why is polymer solution aging process important?
It ensures full hydration and activation of polymer molecules.
5. What industries use polymer dosing systems?
It is widely used in municipal, industrial, textile, and chemical wastewater treatment.
6. What is the advantage of automatic dosing system over manual mixing?
It provides higher accuracy, stability, and continuous operation.
Contact us to get your quotation now.
Get in touch with our engineering team.
