Application fields of Rotary Evaporator: scientific research, chemical industry, food processing, aerospace, medicine, biology, petroleum, etc.
Product Name | Rotary Evaporator |
Bracket material | Stainless steel |
Rotary bottle | 5L |
Receiving bottle | 3L |
Plastic spray anti-corrosion pot shell size | 310*320*240mm |
Stainless steel pot liner size | 280*170mm |
Floor size | 350*330mm |
Rotation power | 40W |
Rotation speed | 0-120rpm |
Heating power | 2KW |
Bath temperature control range | 0~400℃ |
Temperature control accuracy | ±1℃ |
Vacuum degree | -0.098mpa |
Lifting distance | 0-120mm |
Power supply | 220V/50HZ |
Dimensions | 700*335*1009mm |
Packing size | 1040*620*410mm |
Package weight | 38kg |
Speed display mode | Digital display |
Temperature display mode | K-type sensor digital display |
Temperature control method | Intelligent temperature control |
Sealing method | PTFE component seal |
Lifting method | Manual lifting |
Features of Rotary Evaporator
- Condenser & collection bottle: The condenser is a serpentine double coil, which can cool quickly and cool down rapidly. The collection bottle is made of high borosilicate glass, strong and safe, and can be collected continuously.
- Rotary bottle & water oil bath: The rotary bottle is made of high borosilicate glass and annealed at high temperature three times. Bathing pot adopts 304 stainless steel heating ring, PID intelligent and precise temperature control.
- Sealing device: It is made of PTFE sealing body and processed by CNC machine tools. Guaranteed air density, high durability and long service life.
- Motor & Governor: High-quality pure copper motor, small size, large torque. The speed regulation adopts stepless speed regulation, with real-time speed display, which is convenient and simple to operate.
