300 kg/h Pellet Extrusion Equipment for Plastic Production

Extrusion Equipment for Plastic Production Product Introduction

This 300 kg/h pellet extrusion equipment is ideal for producing plastic pellets for various applications, including injection molding, blow molding, and extrusion processes. It supports a range of thermoplastic materials, ensuring uniform melting and high-quality pellet output. The machine features a robust screw design, multi-zone temperature control, automatic material feeding, and a cooling system for stable production. With PLC control and touch screen interface, operators can easily monitor and adjust production parameters, maximizing efficiency and reducing downtime.

Working Principle：

Raw plastic materials are fed into the hopper and transported by a screw into the heated barrel. The screw compresses and melts the material, which passes through a die plate to form uniform strands. These strands are cooled and cut into consistent pellets using a water bath and pelletizer. Multi-zone heating and precise screw design ensure even melting, consistent pellet size, and high throughput.

Technical Specifications：

Production capacity	300 kg/h (depending on material and die configuration)
Screw type	Single-screw or twin-screw (customizable)
Screw diameter	65–90 mm (depending on model)
L/D ratio	20:1–30:1 (customizable)
Heating zones	4–6 zones with independent temperature control
Motor power	15–22 kW (depending on screw type)
Voltage	AC 380V, 50/60Hz, 3-phase
Feeding method	Automatic hopper feeding with screw conveyor
Pelletizer type	Water-cooled or air-cooled cutting pelletizer
Pellet size	2–5 mm (adjustable by die plate)
Control system	PLC + Touch screen interface
Machine dimensions	4500×1200×1800 mm (L×W×H)
Net weight	2200–2500 kg

Main features：

• High precision twin-screw or single-screw extrusion for uniform pellet size and consistent quality
• Multi-zone heating barrel for precise temperature control and uniform melting of thermoplastics
• Automatic feeding system with adjustable screw speed for continuous production
• Efficient cooling and pelletizing system to ensure stable pellet shape and high throughput
• PLC control and touchscreen interface for easy operation and monitoring

Application Scenarios：

• Production of plastic pellets for injection molding industries
• Raw material pellet production for blow molding and extrusion applications
• Recycling of thermoplastics into reusable pellets
• Manufacturing of PE, PP, PVC, and other polymer-based pellets
• Production of specialty thermoplastic pellets for automotive, construction, and consumer goods

FAQ

• What types of plastics can this machine process?
  It can process PE, PP, PVC, ABS, PS, and other thermoplastics.
• What is the production capacity of this machine?
  The machine has a production capacity of 300 kg/h, depending on material type and extrusion parameters.
• Can it handle recycled plastics?
  Yes, it is designed to process both virgin and recycled plastics efficiently.
• How precise is the pellet size?
  Pellet size can be controlled within ±1–2 mm depending on the die and material.
• Is the screw customizable?
  Yes, screws and die plates can be customized for different material types and pellet sizes.

Contact us to get your quotation now.
Get in touch with our engineering team.
