20-Disc Agricultural Disc Plow for Field Soil Turning

Agricultural Disc Plow Product Introduction

The Agricultural Disc Plow is a heavy-duty soil cultivation implement engineered for land preparation and ground breaking applications. With a 68-inch working width and 18-inch notched discs made from forged alloy steel, it provides strong penetration and effective soil turning. Built with a solid square tube frame and reinforced gang tubes, it ensures structural durability during demanding field operations. This equipment helps farmers and agricultural contractors efficiently loosen compacted soil, improve aeration, and prepare seedbeds for planting. It is suitable for use with skid steers, tractors, and loaders equipped with a universal skid steer mount, making it ideal for small to medium-scale farming and land management tasks.

Product Parameter Table

Frame Width	78”
Disc Height	20”
Weight	890 lbs
Discs	20 set
Linkage	3 Point Mounted

Main Features

• Universal skid steer mount design ensures wide equipment compatibility and quick attachment to tractors, loaders, and skid steer machines.
• 78-inch working width improves operational efficiency by covering larger field areas in less time during soil preparation.
• Manually adjustable 10-degree gang angle allows flexible adaptation to different soil textures and cultivation requirements.
• 18-inch notched alloy steel discs provide enhanced soil penetration, improved wear resistance, and consistent tillage performance.
• Reinforced square tube frame with 2″×3″ gang tubes increases structural strength and stability under heavy-duty field conditions.
• Greasable square flange bearings and 1-1/8″ square axles reduce maintenance frequency and extend service life.

Application Scenarios

• Farm field soil breaking and primary land preparation
• Seedbed preparation before crop planting
• Orchard and vegetable field cultivation
• Ground leveling and soil aeration improvement
• Agricultural land renovation and compaction relief
• Small to medium farm mechanized tillage operations
