1. Cooperate with US BRIGGS &STRATTON Engine to meet USA emission demand.
Other factories can only use a common diesel engine, which can not meet USA and Europe emission demand.
2. The hydraulic pipes are all imported from Continental AG Germany Company. Not Easy to leak.
Other factories use lower quality high pressure pipes, leaks everywhere after one year.
3. 100 kg counterweight is added to the rear of the machine which makes the machine work more stable and powerful.
4. The whole vehicle is shot blasted, pickled, phosphated, and sprayed, which increases the adhesion of the paint molecules, and is more durable, non-bleaching and smoother.
Product Information
Technical Details
Overall Dimension(LxWxH) | 90 X 39 x 82 in |
Wheelbase | 35 53/64 in |
Total Length Of Track | 48 27/64 in |
Platform Ground Clearance | 14 61/64 in |
Platform Back Turming Radius | 30 55/64 in |
Chassis Width | 35 9/32 in |
Track Width | 7 3/32 in |
Chassis Ground Clearance | 5 13/64 in |
Track Height | 12 19/32 in |
Weight | 1829.83lbs |
Digging Bucket Capacity | 0.025cbm/583.25lbs |
Bucket Width | 14 61/64 in |
Bore Stroke | Single Cylinder, Fan Cool |
Rated Power | 7kw/3000r/min |
Displacement | 6.8ml/r |
Main Pump | G5-6 |
Travel Speed | 1.5km/h |
Additional Information
Max.Digging Depth | 64.96 in |
Max.Vertical Digging Depth | 54.13 in |
Max.Digging Height | 102.76 in |
Max.Dumping Height | 72.83 in |
Max.Digging Radius On Ground | 112.20 in |
Min.Rotation Radius | 52.36 in |
Max.Upgrade Height Of Bulldozer Blad | 13.58 in |
Max.Digging Depth Of Bulldozer Blade | 10.04 in |
